CS41H 16C DN15 Cast Steel Free Floating Ball Type Steam Trap Cast Steel Thread Drain Valve

Product Overview

Description

CS41H-16C DN15 Cast Steel Free Floating Ball Type Steam Trap Cast Steel Thread Drain Valve



• Shorter start-up time with X-element
• Improved process heating efficiency
• High allowable back pressure
• Continuous condensate discharge
• Reduced steam losses
• Ideal for condensate recovery
• Erosion-resistant design

Features

Integral strainer.
Free-floating stainless mechanism auto-discharge orifice at the top of trap.
With continuous air venting at steam temperature.
Continuing or interrupt drain characteristic.
Maximum allowable working pressure:
PN16: working pressure 16barg.
PN25: working pressure 25barg.
Maximum allowable working temperature:
PN16: working temperature 250°C
PN25: working temperature 350°C
Test shell:
PN16: working pressure 24barg.
PN25: working pressure 37.5barg.
Fluid application: vapor, condensation.
Media minimum temperature: 25°C
End Thread: NPT, BSP, BSPT, DIN.

Safety/Quality Approvals

ISO 9001; PED 2014/68/EU

For more details and varieties please feel free to contact us.We sincerely welcome your enquiries.



Contact: vmv6ATvmv-valve.com

Tel: 86 577 67978268

Mob: 86 13656773046
