12mm Nomex High temperature nomex expandable braided sleeving

Share on (62219014376):


Price:$6.18 - $6.20

Quantity:


Product Overview

Description


Product Description

Nomex Braided Expandable Sleeving

◆ Nomex Braided Expandable Sleeving is fabricated from high quality yarns that will not burn and will withstand continuous exposure to temperatures of 662°F / 350°C. It provides excellent protection for industrial wires, cables, hoses (hydraulics), tube and pipes and also provides thermal insulation and personnel protection.
◆ Nomex Braided Expandable Sleeving resists most acids and alkalis and is unaffected by most bleaches and solvents. It is highly flexible and conformable.


 ◆ It is widely used for a wide range of applications such as military,aerospace,race car,fire department to protect the cable and wire from the dangers that come with working in and around intense flame and heat.

◆ Nomex Flame Resistant Braided Sleeving is incredibly strong, with a tensile strength of 90,000 psi.
◆ The densely Nomex sleeve provides full coverage and protection on even the most exposed applications.
◆ Nomex sleeve cuts easily with regular scissors and the smooth surface eases installation even over long wire runs.

\t

Part No
\t
Size
\t
Expanded Range
\t
Standard Packing
\t
Inch
\t
MM
\t
 Min.(I)
\t
 Max.(O)
\t
m/Roll
\t
LS-NX-003
\t
1/8''
\t
3mm
\t
2.4mm
\t
6.4mm
\t
1000m/Roll
\t
LS-NX-006
\t
1/4''
\t
6mm
\t
3.2mm
\t
11.1mm
\t
500m/Roll
\t
LS-NX-010
\t
3/8''
\t
10mm
\t
6.4mm
\t
12.7mm
\t
350m/Roll
\t
LS-NX-012
\t
1/2''
\t
12mm
\t
7.6mm
\t
19mm
\t
300m/Roll
\t
LS-NX-016
\t
5/8''
\t
16mm
\t
9.5mm
\t
25.4mm
\t
300m/Roll
\t
LS-NX-019
\t
3/4''
\t
19mm
\t
12.7mm
\t
31.8mm
\t
300m/Roll
\t
LS-NX-025
\t
1''
\t
25mm
\t
15.9mm
\t
38.1mm
\t
200m/Roll
\t
LS-NX-032
\t
1-1/4''
\t
32mm
\t
19.1mm
\t
44.5mm
\t
150m/Roll
\t
LS-NX-038
\t
1-1/2''''
\t
38mm
\t
25.4mm
\t
63.5mm
\t
100m/Roll
\t
LS-NX-045
\t
1-3/4''
\t
45mm
\t
31.8mm
\t
69.9mm
\t
100m/Roll
\t
LS-NX-051
\t
2''
\t
51mm
\t
38.1mm
\t
88.9mm
\t
100m/Roll
Detailed Images
Certifications
Exhibition
Our Company

Total Solution ProviderDongguan Liansi electronics Co. Ltd is specilized in manufacturing Braided expandable sleeves,connector series and Optical Fiber cables more than 7 years. Overall our products are compliant UL, ROHS, ISO9001:2008 systerm. low-smoking and Halogen free approvals.


From the design of new products to the re-engineering of existing products for quality improvement or cost reduction, our engineering team is capable of meeting our customers' requirements. Other advantages:Plastic injection, molding, automatic assembly equipment and automatic train lines.

Hold hundred sets of high-speed braid machines which can do colorful, multi-patterns ,multi-specs sleeve. (2MM-150MM) . Sample lead time:0.5-3 days

laboratory

Office

WorkShop

Our Service

◆OEM Manufacturing welcome: Product, Package.

◆ Sample order.

◆We will reply you for your inquiry in 24 hours.

◆ after sending, we will track the products for you once every two days, until you get the products. When you got the goods, test them, and give me a feedback.If you have any questions about the problem, contact with us, we will offer the solve way for you.


FAQ

1.What is the MOQ ?
◆100 meters for our own available designs.


2.Can I get a lower price if I order large quantities?
◆Yes, cheaper prices with more bigger size orders.

3.What is your terms of payment?
◆T/T 100% in advance.

4.What is your terms of delivery?
◆FOB,CIF,EXW.

5.Can you produce according to the samples?
◆Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.

6.What is your sample policy?
◆We can supply the sample, the customers just need to pay the courier cost.

7.Can I mix different designs?
◆sure!

8.How about your delivery time?
◆Generally, it will take 1 to 7 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
