a3 Automatic paper feed label sticker digital die cutting machine sticker label cutting machine

Max media width

350mm

Max cutting width

340mm

Blank size

5 mm blank around the material

Main board

High speed Arithmetic Microprocessor, 4MB cache

Interface;

USB/U DISK/WIFI(option)/NETWORK(option)

Control penal

Thin film switch (life 1 million times)

Driver

Digital DC, step motor, Micro-step Driver

Display

2*16 high resolution LCD

Drawing instruction

DMPL/HP-GL

Max cutting speed

800mm/s

Max cutting thickness

1mm

Pressure

50g~800g  (160 grades digital Adjustable)

Mechanical precision

0.025mm

Repeatable precision

< ±0.1mm

Power supply

AC90~240V/50Hz~60Hz

Positioning model

Bounded system, random original point setting

Working model

Roller,Single,Multiple media Auto-feeding

Operational environment

+5℃~ +35℃,relative humidity 30%~70%

CorelDRAW

X3-X8\2017\2018

Operating System

WINXP-WIN10
