Top one solar inverter 12v 220v 5000w 10 kw off grid tie hybrid solar inverter
- Category: >>>
- Supplier: Foshan Top One Power Technology Co. Ltd.
Share on (62221497899):
Product Overview
Description
Topone solar inverter 12vdc 220vac 1kw 2kw 3kw 4kw 5kw 6kw off grid tie hybrid solar inverter
Product Description
Details data sheet
| MODEL | GI-102 | GI-152 | GI-202 | GI-302 | GI-402 | GI-502 | GI-602 | GI-702 |
| RATED POWER | 1KW | 1.5KW | 2KW | 3KW | 4KW | 5KW | 6KW | 7KW |
| SURGE POWER | 3KW | 4.5KW | 6KW | 9KW | 12KW | 15KW | 18KW | 21KW |
| INPUT | ||||||||
| VOLTAGE | 220VAC | |||||||
| SELECTABLE VOLTAGE RANGE | 145-265VAC | 170-265VAC | ||||||
| FREQUENCY RANGE | 50HZ/60HZ±5HZ | |||||||
| OUTPUT | ||||||||
| AC VOLTAGE REGULATION(BATT. MODE) | (DC BATT.MODE)220VAC±3% | |||||||
| TANSFER TIME | ≤5ms | |||||||
| WAVE FORM | PURE SINE WAVE | |||||||
| BATTERY | ||||||||
| BATTERY VOLTAGE | 12V/24V | 24V/48V | ||||||
| FLOATING CHARGE VOLTAGE | 13.8V(12V)/27.6V(24V)/55.2V(48V) | |||||||
| OVERCHARGE PROTECTION | 17V(12V)/34V(24V)/68V(48V) | |||||||
| AC CHARGER | ||||||||
| STANDBY POWER COMSUMPTION | 15W | |||||||
| MAXIMUM AC CHARGE CURRENT | 35A | |||||||
| PHYSICAL | ||||||||
| DIMENSION,D*W*H(MM) | 530*335*250MM | 740*335*275MM | ||||||
| G.W.(KGS) | 12 | 14 | 15.6 | 20.3 | 26.9 | 30 | 34.4 | 35 |
| ENVIRONMENT | ||||||||
| HUMIDITY | 0~95%(NO CONDESNSATION) | |||||||
| OPERATING TEMPERATURE | 0~60℃ | |||||||
| STORAGE TEMPERATURE | 0~60℃ | |||||||
| *PRODUCT SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT FURTHER NOTICE | ||||||||
