Splicing Screen Ingscreen Ultra Thin Bezel Tv Lcd Smart Big Panel Video Wall
US $488.00-$533.00
Видеоконтроллер 55 дюймов DID Panel 4k 3,5 мм bezel 4x3 lcd video
- Category: Splicing Screen >>>
- Supplier: Shenzhen Kosintec Co. Ltd.
Share on (62224456944):
Product Overview
Description
55inch DID Panel 4k 3.5mm bezel 4x3 lcd video wall screens video controller
Features:
42" TFT LCD video wall display ,
Industrial grade A+ LCD panel, higher performance,
18mm inter-screen gap
16.7M colors, fine and natural image,
1920x1080resolution (16:9),
1500:1 High contrast ratio,
500cd/m² high brightness , no jitter,
8ms fast response time,
2* BNC, 1*VGA,1*YPbPr/YCbCr video inputs.
Over 60,000 hours lifespan, 7x24 hours working,
Embedded processor to support up to 15*15 display units,
Progressive scan, display units separation accuracy up to 1 pixel,
Integrated 3D Video Decoder , 2D Scaler, 10 bit digital processing ,
Adaptive dual 3D Comb filter to eliminate color interference,
Intelligent temperature control system to keep 55 Celsius degrees below inside the housing,
Compact structure, metal housing to reduce or eliminate electromagnetic interference, no harmful radiation, Multi-languages OSD menu, friendly human machine interface
| Technological Parameters: | |
| Model | FT-P4218LL—E |
| Panel size | 42" /a-Si TFT-LCD |
| Inter-screen gap | 18mm |
| Colors | 16.7M |
| Resolution | 1920x1080 |
| Pixel Pitch | 0.681mm(W)×0.681mm(H) |
| Brightness | 500cd/m² |
| Contrast Ratio | 1500:1 |
| View angle | 178°/178° |
| Response time | 8ms |
| Material of housing | Metal |
| Color of housing | Black |
| Systems | PAL/NTSC/SECAM |
| Operation method | Remote control optional |
| SATA interface | RS232 (RJ45-8) |
| SATA loop-out | RS232 (RJ45-8) |
| OSD languages | Chinese, English, multi-languages optional |
| VGA input | 1(D--SUB 15PIN) |
| Composite video input | 2(BNC*2) |
| YPbPr\\YCbCr input | 1 (BNC*3) |
| Frequency | 50Hz, 60Hz ,70Hz |
| Power supply | AC100~240V,50/60Hz |
| Power consumption | ≤230W |
| Standby power consumption | <1W |
| Operation temperature | 0~50℃ |
| Storage temperature | Minus 20ºC~+60ºC |
| Operation & Storage humidity | 20%~80% |
| Installation methods | Embedded, wall-mount, floor-standing |
product description
- Fully customizable for 3x1, 2x2, 3x2, 2x3, 4x2, 2x4 or 1x3 Video walls!
- SUPER NARROW BEZEL With a bezel-to-bezel measurement of just 4.9mm (47") and 3.5mm (55") our video walls create a stunning visual canvas that is easily installed.
- Higher brightness uniformity 90% ensures high quality image delivered across displays.
- WIDE VIEWING ANGLE accurately displays an image is quality and color at a 178° ultra wide viewing angle.
- Premium Displays present crystal clear images in both landscape and portrait orientations without hot spots until screen surface temperature rises above 230°F.
- Ultra HD resolution, panel brand: Sumsung/LG/AU.
- Provides a perfectly flat viewing surface for graphic and data video projection.
- Designed for permanent mounting to the wall or in a wall opening.
Mass comment
More types of produc
Company Information
Transport Packaging
FAQ
Q1: Are you a factory or a trading company?
A : We are a OEM/ODM factory.
Q2: What payment methods your company accept?
A : We accept most of the payment methods, Flexible Payment term: support T/T, L/C, Westunion, Paypal.
Q3: How long is the warranty time for your products?
A:1-year warranty, lifetime maintenance.
Q4: What will you do if the product be nature damange within warranty time and how about out that time?
A : Well, we will give some quite simple questions to help us confirm the damaged part. Once it confirmed, the free replacement will be send. Also, we will just request a very low price for replacement part, if the product out of warranty time.
Q5: Can I customize the product I ordered?
A : Abusolutely yes, customizatiion offer from customers are most welcome in our company.
Q6:Can I order a sample?
A:We have a very strong quality control Samples are always available for checking quality and can be dispatched to you very quickly.
Q7:What are your advantages?
A : We have our own ERP systems : Shorten lead times at low cost with responsive production planning.
Q8:What kind of design and development capabilities do you have?
A:artwork/ Instruction manual/ product design according to customer's requirement.
Q9:What's the shipment terms and delivery time of your company?
A : Well, they depends on the quantity of your order.As you know ,we need time to manufacture the machines.but mostly ,the shipment time is 3-8 working days after delivery.For Delivery way, for Sample and Bulk order < 100KG, we will kindly suggestExpress and Air freight, when Air freight and Sea shipping for Bulk order >100KG.As for detailed cost, it depends on your final order.
