The rotary dryer consists of cylinder tube, drying system, fuel system, air pollution control system ,feeding and discharging end.
Working Principle
The rotary dryer is made up of a large, rotating cylindrical tube. The dryer slopes slightly so that the discharge end is lower than the material feed end in order to convey the material through the dryer under gravity. Material to be dried enters the dryer, and as the dryer rotates, the material is lifted up by a series of internal fins lining the inner wall of the dryer. When the material gets high enough to roll back off the fins, it falls back down to the bottom of the dryer, passing through the hot gas stream as it falls.
Technical Parameter
Model
Cylinder
Motor
Dimension (L*W*H)(mm)
Weight (t)
Volume
RPM
obliquity
Model
Power
(m3)
(r/min)
(%)
(kw)
ZTφ1.0*10
7.85
6.73
3-5
Y132M2-6
5.5
10000*1875*2069
7.6
ZTφ1.2*6
6.8
5.8
3-6
Y132M2-6
5.5
6000*2159*2475
8.5
ZTφ1.2*8
9.1
5.8
3-7
Y132M2-6
5.5
8000*2159*2475
9.9
ZTφ1.2*10
11.31
5.8
3-8
Y160M-6
7.5
10000*2159*2475
11.9
ZTφ1.2*12
13.57
5.8
3-9
Y160L-6
11
12000*2159*2475
13.5
ZTφ1.5*8
14.14
4.8
3-10
Y160L-6
11
8000*2655*2895
14.7
ZTφ1.5*10
17.67
4.8
3-11
Y160L-6
11
10000*2655*2895
15.9
ZTφ1.5*12
21.2
4.8
3-12
Y180L-6
15
12000*2655*2895
17.4
ZTφ1.5*14
24.9
4.8
3-13
Y180L-6
15
14000*2655*2895
18.3
ZTφ1.8*10
25.45
4.59
3-14
Y180L-6
15
10000*3060*2980
17.9
ZTφ1.8*12
30.5
4.59
3-15
Y200L1-6
18.5
12000*3060*2980
19.9
ZTφ1.8*14
35.1
4.59
3-16
Y200L1-6
18.5
14000*3060*2980
21.8
ZTφ1.8*18
45.8
4.59
3-17
Y200L2-6
22
18000*3060*2980
25.3
ZTφ2.2*12
45.6
4.43
3-18
Y200L2-6
22
12000*3620*3570
30.3
ZTφ2.2*14
52.1
4.9
3-19
Y200L2-6
22
14000*3620*3570
32.2
ZTφ2.2*18
68.4
4.9
3-20
Y225M-6
30
18000*3620*3570
35.2
ZTφ2.2*20
70
4.9
3-21
Y225M-6
30
20000*3620*3570
38.1
ZTφ2.4*14
63.3
3.85
3-22
Y225M-6
30
14000*3860*3760
39.9
ZTφ2.4*24
109
6
3-23
YCT315-4B
45
24500*3000*3900
54.8
ZTφ2.5*20
123
7.6
3-24
YVP225M-4P
45
23600*3000*4800
55.5
ZTφ3.0*20
147
3.9
3-25
Y315L-4
80
25000*4900*5000
103.8
