Product Overview

Description




Product Description



1. Function of the Y81-250 Automatic baler



Y81-250 Automatic baler used to crush, cut and bale a wide range of scrap metal. They could deal efficiently and quickly with metals scraps, whether it’s something as small as Cans,Aluminium and steel turnings and Wire scrap, or as large and robust as steel sheet, washing machines, other white goods and whole vehicles.

Choose a metal automatic baler from YMS and benefit from a reliable and fit-for-purpose solution for your recycling needs.










2. Specification of the Y81-250 Automatic baler



SPECIFICATION

Model

Y81-250

Main Power

22Kw*2

Oil Pump

160ml/r*2

Voltage Supply

380V/3phase/50Hz (Customized)

Main Pressure Force

2500Kn (250Ton)

Compression Chamber(L*W*H)

2000*1400*900mm

Bale Size (W*H) (Steel Scrap)

450*450*(500~900)mm

Bale Weight  (Steel Scrap)

~300Kg

Bale Density (Steel Scrap)

~1.8 t/m3(Density varies with what and how much metal scrap to press)

Bale Capacity  (Steel Scrap)

~4500 kg/hour (Including the feeding time)

Single Cycle Time (No-Load):

~120S

Bale-discharge

Turn-out

Machine Operation

Manual operation

Host Overall Dimensions (L*W*H)

~6000*4400*3200mm

Machine Weight (Approx.)

21,000Kg

Oil Capacity

2800L ( hydraulic oil ideal working temperature requirement:  20℃~55℃ )

Oil Band

46# or 68# Abrasion-resistant hydraulic oil.(-10℃~60℃ )

Loading Container

20GP+40FR Container could load one set.

Notes:

All mentioned capacity are based on our previous experience and knowledge.

A final statement to the capacity is only possible after a test with original material.

Bale size, Compression chamber , Bale-discharge and Machine operation could be Customized.



3. Feature of the Y81-250 Automatic baler

l Fully automatic working cycle

l Customized Compression Chamber and bale size.

l Easy operated by one operator with remote control.



 4. Components of the Y81-250 Automatic baler



STANDARD COMPONENTS

Mechanics-M

Hydraulics-H

Electrics-E

M-1.Main unit Frame

H-1.Hydraulic oil tank

E-1.Electrical cabinet

M-2.Compression chamber

H-2.Motor and Pump

E-2. Operate panel with buttons

M-3.Main cylinder

H-3.Valve system

E-3. Instrumentation & Safety devices

M-4.Side cylinder*2

H-4.Over heating protection



M-5.Turn cylinder

H-5.Oil filter



M-6.Cover cylinder

H-6.Air filter



M-7.Lock cylinder

H-7.Hydraulic gauge





5. Main Application of the Y81-250 Automatic baler

 Metal Scrap.png



6. Delivery, Shipping and warranty of the Y81-250 Automatic baler

DELIVERY

The standard Automatic baler is about 50 days after receiving the deposit..

If customized machine, delivery time depends on the negotiation with both.



SHIPPING

Before loading, all parts of the automatic baler will be film wrapped, and firmly fixed in the container by the steel wire.

Shipped by sea or train.



WARRANTY

This automatic baler machine is guaranteed for 12 months.

Warranty shall start at time of initial installation at customer’s location, and not later than 15 months from delivery date.

Within the guarantee period, in the event of any malfunction caused by the quality of the commodity, We will replace defective parts free of charge.Defective parts are to be returned to YMS (Seller). Wear parts are exclusive from this warranty. We also provide technical support and parts sell for the whole life span of the automatic baler machine.

.
