HDMI in Modulator HDMI to RF Modulator Coaxial Cable Video Splitter
- Category: >>>
- Supplier: Ask Technology Co. Ltd.
Share on (62233728070):
Product Overview
Description
HDMI in Modulator HDMI to RF Modulator Coaxial Cable Video Splitter
HDMI in Modulator HDMI to RF Modulator Coaxial Cable Video Splitter
HDMI TO DVB-T Modulator
HDMI Extender By Coaxial
Model No:HDEX0011M1
DVB-T H.264 Modulator are designed to make your A/V device use more convenient, comfortable, productive and cost-efficient.
The HDMI TO DVB-T Modulator can convert HDMI signal to HD digital TV signal based on DVB-T CATV transmission mode. dvb-t modulator applies RF modulation technology characteristic to realize the HD signal to HD digital TV signal conversion and transmit via coaxial cable over long distance up to 500 meters. By a CATV network mixer,the Modulator over Coaxial cable supports pair to pair and multiple to multiple video matrix.
Specifications:
HDMI in Modulator HDMI to RF Modulator Coaxial Cable Video Splitter
Detailed Description
HDMI to RF Modulator HDMI modulator converter
HDMI in Modulator HDMI to RF Modulator Coaxial Cable Video Splitter
>>Introduction
The HDMI TO DVB-T Modulator can convert HDMI signal to HD digital TV signal based on DVB-T CATV transmission mode. The product applies RF modulation technology characteristic to realize the HD signal to HD digital TV signal conversion and transmit via coaxial cable over long distance up to 500 meters. By a CATV network mixer,the Modulator over Coaxial cable supports pair to pair and multiple to multiple video matrix.
HDMI in Modulator HDMI to RF Modulator Coaxial Cable Video Splitter
>>Features
HDMI in Modulator HDMI to RF Modulator Coaxial Cable Video Splitter
|
>>Operating and Connection
HDMI To Dvb-t Modulator Converter HDMI Input BNC Output Over Coaxial Cable Digital Tv Modulator
HDMI in Modulator HDMI to RF Modulator Coaxial Cable Video Splitter
>>Specifications
HDMI in Modulator HDMI to RF Modulator Coaxial Cable Video Splitter
HDMI resolution ……………………………………..24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i HDMI Audio Format……………………………………………………………………………………..LPCM RF frequency range…………………………………………………………………………...139~950 MHz RF Channel B/W…………………………………………………………………………..................7/8 MHz The number of Channel……………………………………............................80 RF Output power…………………………………………………………………..............................-6dBm RF Connector type…………………………………………………………………The imperial F type/BNC Coaxial cable Characteristic impedance…………………………………………………………………75Ω Coaxial cable types………………………………………………………………………SYV-75/RG59 etc. RF transmission distance………………………………………≤500mSYV-75-5 coaxial standard cable TX Max working current ……………………………………….……….…….…. 650mA Power adapter format Input ……......….….…….…….…….…. AC 100V~240V 50HZ/60Hz, DC5V/2A Operating Temperature range ……..…………….……………. -10 to +45℃ Storage Temperature range……………………………………………………………………. -20 to +60℃ Operating Humidity range ………………………….….……….……….10 to 90%RH (No Condensation) Storage Humidity range………………………….….……….……………5 to 95%RH (No Condensation) Case Dimension (L x W x H) ………………….…………………………….94x74x28 (mm) Weight …….………………………………………………….………………..…… 120g |
>>Notes
HDMI in Modulator HDMI to RF Modulator Coaxial Cable Video Splitter
Pls use the machine as the instruction listed to keep the long use lifetime of the machine. 1. The machine should be placed at the spot far from the Damp, High-Temperature, Dusty, Erosive, and oxidative environment. 2. All parts will be free from the strong shake, hit, fall. 3. Touching the power adaptor with the wet hands is prohibited. 4. Pls hold the power adaptor head and do not pull the power cord when cut off from the socket. 5. Pls turn the power off when the machines not used for long time. 6. Pls do not open the cover and do not touch the inside parts. 7. Pls use the original factory power adaptor. |
HDMI in Modulator HDMI to RF Modulator Coaxial Cable Video Splitter
Business terms
Business Terms
HDMI in Modulator HDMI to RF Modulator Coaxial Cable Video Splitter
| Accepted Delivery Terms: | FOB, CIF, EXW |
| Accepted Payment Currency: | USD, EUR, HKD, GBP, CNY |
| Accepted Payment Type: | T/T, L/C, Western Union, Cash |
| Nearest Port: | Shenzhen |
Our services
1. We have professional research team. All products are designed by ourself, so we are experienced in any doubts you have on the product.
2. As a manufacturer, we have our own factory, so we definitely have price advantage on our models!
3. All products are 100% tested working before sending to you.
4. We have professional sales team, so please do not hesitate to contact us if you have any question!
FAQ
Q1.What is your MOQ?
A: Our MOQ is not the same based on different items. Small orders are also welcome, but the unit price is also difference from wholesale price.
Q2.What package do your use for the product?
A:Usually we have professional neutral package for the products. Customized package are also available based on certain MOQ.
Q3.What is your main market?
A: Asia Australasia Central/South America Eastern Europe Mid East/Africa North America Western Europe
HDMI To Dvb-t Modulator Converter HDMI Input BNC Output Over Coaxial Cable Digital Tv Modulator
Contact
How to Contact us?
Would like to know more about the product? Send us inquiry, click "Send" now! Or contact us by follow ways:
How to contact us?
Phone /Wechat: + 86 13632725374
Whatsapp:+86 18278302141
Qq: 1506750002
Or just send me an inquiry and contact online.
