Stainless steel and Aluminum Channel Letter bender for 3D signage making

Product Overview

Description

      Stainless steel and Aluminum  Channel Letter bender for 3D signage making



Product description



power supply	AC220V
working power	3500w
Air compressor	0.4-0.6Mpa
Control Axis	7Axis
Bending Radius Min.	7mm(with retractable altering bending mode 12mm(roller-bender head)
Applicable Material	Aluminum coils, Alumium Extrusion profile, stainless steel, Galvanized sheet
Material Thickness	0.4-1.2mm
Material height	20-160mm
working principle	auto feeding, auto slotting, auto bending
Net weight	360kg



Advantage:

1.This type YIKE-15UL channel letter bending machine can bend all material, such as Aluminum coils, aluminum extrusion profile, cooper, stainless steel, galvanized sheet, and iron sheet ect.

2.Have two professional cutting tool for both stianless steel and aluminum material, one is planner cutting, another is round cutter.

3.Both bend system, one is roller bending , another is retractable alternating blade clinch bending Mode. roller bending for big angle bending, the latter is for small angle.

4.high precision and high speed





Packing and shipping

Sample



 Company Exhibition

our service

1.We supply free training in our facotry, and also can help on line by WeChat, Skyp etc.

2.Supply oversea training if you need.butyou will pay for all train fee.
