0.5T 15T Latest Fixed Column Type Cantilever Jib Crane with design calculation

Product Overview

Description

                                  0.5T-15T Latest Fixed Column Type Cantilever Jib Crane

OVERVIEW

Column mounted jib crane is a kind of crane that fixed on the ground. Its operation area is circular due to its has a rotatable cantilever. Combined with hoist unit like electric hoist, chain hoist, chain block, it can realize transportation of cargos in its coverage.

APPLICATION

It’s widely used in production lines, assembly lines and work station of machine tools, mines and workshops, warehouses, docks, etc.

FEATURE & ADVANTAGE

Small space occupied, easy installation, convenient for workers to use, flexible rotation , high efficiency.

INSTALLATION

1 . Column installation:

Lift the column vertically. Set all bolts in foundation right through bolt holes on bottom flange of the column. Then adjust column verticality and tighten all nuts.

2. Arm/jib/cantileverinstallation

Before installation, lifting hoist should be installed on the arm/jib/cantilever and fixed.

Aligning shaft of column to turntable hole at end of jib/arm, then assemble arm and column together slowly. After parts are in place, tighten the fixing bolts. Then install the power supply ring. Test beam rotation with a rope and rotating should be flexible without jamming and abnormal phenomenon.

3.Drive unitinstallation:

Make cycloid reducer match with ring gear on column. Make sure that drive gear meshes with large ring gear, then fixed the reducer to flange by bolts..

parameter

type:BZ Model 360 Degree Rotate

Lifting capacity:0.5-15 Ton

litfing height:1m-10m

working duty:A3
