Carbonda CFR515 D disc brake road bike AERO frame set BB86
- Category: Bicycle Frame >>>
- Supplier: Shenzhen Carbonda Sports Equipment Co. Ltd
Share on (62237726739):
Product Overview
Description
Product Description
Please consult us for detailed price
Details
| Model No :CFR515-D | ||||||||||
| USE: | Road bike AERO | |||||||||
| Material: | 100% full toray carbon fiber | |||||||||
| Size: | XXS | XS | X | M | L | XL | ||||
| weight of the frame in M : | 1200 ± 50 G | |||||||||
| weight of the fork: | 450 ±15G | |||||||||
| Weave: | UD | |||||||||
| BB(bottom bracket): | BB86;to order | |||||||||
| Brake: | Flat mount disc brake | |||||||||
| Headset size : | φ:1-1/8" - 1-1/2" | |||||||||
| Max tire size: | 700*23mm | |||||||||
| Test : | EN standard test （ in house） | |||||||||
| Technology: | EPS molding | |||||||||
| Feature : | All hidden cable design | |||||||||
| Full housing cable design | ||||||||||
| DI2 group set compatible | ||||||||||
| Disc brake | ||||||||||
| Service: | design and painting | |||||||||
| Packing list ( per set ) : | frame , fork , seatpost, stem , handle bar , headset ,axles, spacers(10MM 20MM ) | |||||||||
| frame warranty : 24 months | ||||||||||
