Cheapest BNC to IP Transformer Passive HD 1080P 4MP 5MP Video balun connector
- Category: >>>
- Supplier: Shenzhen Eborm Technology Co. Ltd.
Share on (62243220114):
Product Overview
Description
Product Description
Features:
Compatible with AHD/CVI/TVI signal
Transmission signal: 720P/1080P
Cable:CAT5/5E/6
Transmission distance to 300M for CVI/AHD,200M for TVI
No power required
Build-in surge&transient protection
Super interference rejection
| ITEM | Specification | |
| Physical Properties | Dimension(L*W*H) | 13.7*11.6*3MM |
| Shell | ABS | |
| Color | Black | |
| N.W. | 60g | |
| Stability | MTBF | >10000H |
| Environmental | Operating Temperature | -10~55℃ |
| Storage Temperature | -20~70℃ | |
| Humidity | 0~95%(no-condensing) | |
| Properties | Transmission signal | 1 channel |
| Transmission distance | AHD/CVI:300M(max) | |
| TVI:200M(max) | ||
| Category Type | UTP CAT5/5E/6 | |
Video transmission properties and port | Coaxial video connector | BNC-M |
| Twisted-pair video connector | Push-terminal | |
| Compatible Format | AHD/HDCVI/HDTVI | |
| Resolution | 720P/1080P | |
| Anti-interference | >60dB | |
| Protection | ESD | 1a contact discharge electricity level 3 |
| 1b air discharge electricity level 3 | ||
| Per:IEC61000-4-4 | ||
| Coaxial cable connector | 2KV(common-code)per:IEC1000-4-5 | |
| UTP cable Connector | 2KV(difference-code),4KV(common-code),Per:IEC1000-4-5 | |
| Impedance | BNC male | 75 Ohms |
| UTP cable | 100 Ohms | |
