Сплит воздушный тепловой насос 4 кВт
- Category: Water Heaters >>>
- Supplier: Guangdong Folansi Energy Saving Equipment Co. Ltd.
Share on (62244778346):
Product Overview
Description
Split Air source heat pump | |||
Model | FAR-04c | ||
technique parameter | Heating capacity | KW | 4 |
btu | 13652 | ||
heating input power | KW | 1.1 | |
cooling capacity | KW | 3.2 | |
btu | 10922 | ||
cooling input power | KW | 1.10 | |
Max outlet temp | ℃ | 60 | |
Rated outlet temp | ℃ | 55 | |
water flow | m3/h | 0.80 | |
water pressure down | Kpa | 18 | |
net(outdoor unit) | kg | 34 | |
gross(outdoor unit) | kg | 46 | |
net(indoor unit) | kg | 18 | |
Gross(indoor unit) | kg | 25 | |
Nosie | db | 48 | |
connect size | inch | 1/4",3/8" | |
indoor unit Specifications | water tank Wall mounted internal machine | ||
power | 220V/1PH/50Hz | ||
net size(outdoor unit) | mm | 780*258*540 | |
packing size(outdoor unit) | mm | 820*300*670 | |
net size(indoor unit) | mm | 400*170*580 | |
packing size(indoor unit) | mm | 450*220*650 | |
Standard configuration | compresor | brand | Hitachi |
qty | 1 | ||
Condenser | Plate heat exchanger / tube in shell heat exchanger | ||
Evaporator | Hydrophilic aluminum foil + internal thread copper pipe | ||
4-way valve | Sanhua or dunan | ||
Throttling device | sanhua electronic expansion valve electronic expansion valve | ||
AC contactor | SHIHLIN | ||
fan power | 50W | ||
cabient | Galvanized white metal sheet or staniless steel | ||
controller | Chinese brand large LCD screen controller | ||
high pressure switch | 3.0/2.4MPa | ||
low pressure switch | 0.02/0.15MPa | ||
working mode | heating or heating/cooling | ||
circulate water pump | wilo RS15/6 | ||
electric heater | optional | ||
refrigerant | R410a | ||
Connect pipe | 5m | ||
1,unit working ambient temperature:-15℃ to 43℃
2,heating working condition:ambient temperature7℃/6℃,inlet water/outlet water40℃/45℃; coling working condition:ambient temperature35℃/24℃,inlet water/outlet water12℃/7℃;
3,indoor unit can is water tank or Wall mounted internal ;
