ZL15 Wheel Loader provides high performance with excellent versatility. Low noise, spacious cab allows operators working comfortable.
Wheel loaders with many different configurations are available to meet your requirements.
Whether you need a wheel loader for use in landscaping, agricultural, construction, waste management, forestry, or mining applications, our wheel loaders make your material handling and loading jobs safer and faster.
Specification
SPECIFICATION OF ZL15 WHEEL LOADER
Engine
Model
Xichai, Xinchai(Euro III Emission)
Rated Power
kw/rpm
37/2300, 36.8/2400
Operating Weight
kg
3900
Rated Loading
kg
1500
Rated Bucket Capacity
m³
0.6
Max. Dumping Height
mm
2700
Dumping Distance
mm
850
Min. Turning Radius
mm
4000
Min. Ground Clearance
mm
270
Max. Grade Ability
°
30
Tire
20.5/70-16
Standard Configuration 1. XiChai engine 33KW 2. Mechanical Joystick 3. Standard bucket 0.6m³ capacity 4. Reverse Camera 5. Heater 6. Isuzu axle 7. Standard tire 20.5/70-16
Options 1. Euro3 XinChai A498BT1 engine 36.8KW 2. Hydraulic Joystick 3. Quick Hitch 4. Tubeless tires, Rubber tires 5. Electric control gear lever 6. Hub reduction axle 7. Air conditioning 8. Attachments such as 4 in1 bucket, pallet fork, snow blade, grappler etc. for different jobs.
