High precision thread ring gages SKD11 material with measuring data
- Category: Gauges >>>
- Supplier: Shenzhen Hosun Precision Co. Ltd.
Share on (62250302786):
Product Overview
Description
Product Description
Thread ring gauges are used to check the outside major diameter and pitch diameter limits on threaded parts
Like many other thread gages, these gages use a GO and NO GO method to determine if the threads fall within the tolerance or the class of fit. Thread ring gages are quite simple to use; if the GO end screws on, and the NO GO end will not screw on past three complete turns, then the part is within tolerance
Thread Ring gages are available in Straight Pipe and Taperpipe styles
Material :
Made of high performance bearing steel GCR15 , high hardenability, high hardness and fatigue strength, good dimensional stability, and SKD11 material are availiable
Tolerance:
Thread tolerance class: 4,5,6,7,8 ,Thread tolerance external thread g, h
Quality Assurance:
Each gages is rigorously tested to ensure that the dimensional data is qualified before leaving the factory, If you still need a calibration certificate from a third-party laboratory, please let us know in advance, this need extra cost
What Thread Ring Checks:
GO gage checks the maximum minor diameter and the maximum pitch diameter size in a part
NO-GO gage checks for the hole not to exceed the minimum pitch diameter size on a part
Like many other thread gages, these gages use a GO and NO GO method to determine if the threads fall within the tolerance or the class of fit. Thread ring gages are quite simple to use; if the GO end screws on, and the NO GO end will not screw on past three complete turns, then the part is within tolerance
Thread Ring gages are available in Straight Pipe and Taperpipe styles
Material :
Made of high performance bearing steel GCR15 , high hardenability, high hardness and fatigue strength, good dimensional stability, and SKD11 material are availiable
Tolerance:
Thread tolerance class: 4,5,6,7,8 ,Thread tolerance external thread g, h
Quality Assurance:
Each gages is rigorously tested to ensure that the dimensional data is qualified before leaving the factory, If you still need a calibration certificate from a third-party laboratory, please let us know in advance, this need extra cost
What Thread Ring Checks:
GO gage checks the maximum minor diameter and the maximum pitch diameter size in a part
NO-GO gage checks for the hole not to exceed the minimum pitch diameter size on a part
Related Products
Gcr15 material ring gauge
We can supply
1. Metric thread plug gauge & ring gauge from M1 to M100 ,accuracy 6H, 5H, 6G; 6g, 6h etc
2. US specification thread plug gauge& ring gauge (suitable for US standard) from No.0 – 80UNF ,accuracy 2B, 3B, 2A, 3A (UNC, UNF, UNE, UN, UNS etc) and taper pipe thread series NPT, NPTF, NPSM, ACME, STUB ACME, BUTT, etc
3.UK thread plug gauge & ring gauge (suitable for European countries standard) from size 1/8 – 40 BSW , BSF and taper pipe thread series with G, RC/R, PT, BA etc
4.For thread insert hole check , ST thread plug gauge and TS ZS thread ring gauge
5.For threaded hole positioning and measuring thread hole center distance Thread positioning gauge (thread vertical gauge, thread gauge)
6.Oil Pipe Series Gauge API series
7.Other series thread gauges: Pg, V1, V2, SM
