PU conveyor belts joint welding machine
- Category: >>>
- Supplier: Ningbo Davison Machinery Manufacture Co. Ltd.
Share on (62250739367):
Product Overview
Description
Product Description
Characteristics
1.NL-5557 high frequency sparking protection system,sensitive.It can protect electron tube,mold and material.
2.High power head of machine,pressure can be adjusted freely
3.It adopts high frequency filtering device to make sure of lowest high frequency interference
4.It adopts coaxial oscillator with low loss.The output power is strong to save the welding time and increase the production output.
5.It adopts stepless heating device:the temperature can be adjusted according to different products.
6.It adopts digital display device to make sure it is easy to adjust and fix position accurately.
7.It adopts preheating protection system,prolong life of electron tube,improve the economic benefit.
8.The traditional process of PVC conveyor belt has been greatly improved.Improve the production efficiency,shorten the welding time,ensure the quality of the products
SPECIFICATIONS
| MODEL | DXHT5-50-E |
| OUTPUT POWER | 50KW |
| FREQUENCY | 13.6Mhz |
| VOLTAGE | 380V |
| UPPER ELECTRODE | 1500X300mm |
| LOWER ELECTRODE | 1850X380mm |
| DISTANCE BETWEEN ELECTRODES | 100mm |
| PRESSURE TYPE | OIL AND AIR BLEND |
| MAX PRESSURE | 50000KG |
| OUTPUT POWER TUNER | ELECTRIC |
| SIZE | 5260X1330X2200m |
Applications:
Certifications
Customer visit
Packaging & Shipping
Company Information
Ningbo DAVISON Machinery Manufacture Co., Ltd. integrates research, production and sales such as below machines and parts:
1. High frequency plastic welding machines (high frequency machine),
2. Ultrasonic plastic welders,
3. Cutting machines,
4. Packaging machines,
5. Skin packaging films, stretch films, protective film, etc.
Various non-standard machinery equipment and imitation of imported equipment are available to the specific requirements of customers. Moreover the design and producing of moulds as well as sampling service can also be offered by us.
Since foundation in 1999, our company has constantly carried forward rigid quality control, guided by customers demand, aimed for customers' satisfaction, persisting on "quality first, customers utmost", and striving to offer optimal products and efficient after-sales service for customers domestic and oversea!
