50L Chocolate ball mill refiner 0086 18638277628

Product Overview

Description

SQM-50 Chocolate ball mill refiner

It is the basic machine to grind chocolate material, as well as oil-bearing material, fluidness and some chemical raw material.



This machine adopts the worm wheel and worm screw driving system, the places contacting with food and the machine outer case are made of excellent alloy steel and stainless steel material. This machine is hand wheel operation with multi functions of grinding, dehydration, deodorization, dilution and emulsification. It is ideal equipment for chocolate production.







BASIC SPECIFICATION:



model	Technical data
SQM-5	Volume: 5L Grinding fineness:20-25um Grinding time: 8-12H Main motor: 2.2kw Electric heating: 500w-220v Weight: 80kg Size: 0.7*0.48*0.63m
SQM-50	Volume: 50L Grinding fineness:20-25um Grinding time: 14-20H Main motor: 6kw Electric heating: 3kw Weight: 160kg Size: 0.9*0.5*0.8m
