HSS Metric/Inch keyway broaching tool set with shim and bushing
US $69.00-$388.00
18pcs HSS Metric Keyway Broach Set 4/5/6/8mm Broaches 12 28 Cutting Broach 5shim
- Category: Broach >>>
- Supplier: Zhengzhou Lanchen Electronic Technology Co. Ltd.
Share on (62252138840):
Product Overview
Description
18pcs HSS Metric Keyway Broach Set 4/5/6/8mm Broaches 12-28 Cutting Broach 5shim
Product Description
Product includes:
Broaches*4pcs
Collared bushings*9pcs
Shims*5pcs
Product description:
4 broaches: 4mmB1 ,5mmB1, 6mmC1, 8mmC1
9 Collared bushings: 12,14,16,18,20,22,24,26,28
5 shims
Product features:
4 broaches and 9 bushings = 18 keyway combinations
All necessary shims
| Broach Size | Style | Correction height(mm) | Leading height(mm) | Broach Dimensions*(mm) | Keyway Width(mm) | Length of Cut * min.-max. |
| 4mm | B1 | 10.8 | 9.66 | 6.45X171.5 | b=4.01 | 19/64 - 1 11/16 |
| 5mm | B1 | 10.8 | 9.66 | 6.45X171.5 | b=5.01 | 19/64 - 1 11/16 |
| 6mm | C1 | 16.64 | 15.02 | 9.64X298.5 | b=6.01 | 25/64 - 2 1/2 |
| 8mm | C1 | 15.95 | 14.62 | 9.64X298.5 | b=8.01 | 25/64 - 2 1/2 |
