1.Cover voltage levels 220V AC and 380V AC. Support single-phase 220V and three-phase 220V/380V pumps,the power from 0.4KW to 37KW. 2.Easy to use The inverters automatically start or sleep only after being connected to solar battery panels without any parameter setting. 3.Highly reliable for using multiple protective measures Including PV over-voltage protection,PV polarity reverse warning,and auto derating against over-temperture,which extend product life. 4.Use advanced MPPT algorithms,ensuring that the solar power tracking efficiency reaches 99% 5.Models of 2.2kW or lower can be configured with boost module,meeting low-voltage work requirements.This reduces the use of solar battery panels and therefore the cost. 6.VFD700-PV series can implement auto switch between solar input and grid input by configuring the boost or auto switching cabinet(meeting lightning protection requirements),implementing 24-hour unattended work. 7.Support the configuration of the GPRS module,which implements remote parameter viewing and control by using the mobile APP. 8.Support the cabinet solution for level IP54.
SPECIFICATION
220V
380V
Max input DC voltage
410V
800V
Recommended MPPT voltage range
270~400VDC
350~750VDC
Recommended input voltage
310V
513V
MPPT efficiency
99.9%
Input channel
2
Rated output voltage
3-phase 220VAC
3-phase 380VAC
Output frequency range
0~60Hz
Max efficiency of the machine
97%
Ambient temperature range
-10 °C~50 °C, derating if the temperature is above 40 °C
