200 Micron Hydroponic Growing Plastic Film Greenhouse for Micro Green and Flowers
- Category: >>>
- Supplier: Chongqing Honyu Global Agri-Tech Co. Ltd.
Share on (62258496024):
Product Overview
Description
Film Greenhouse
200 Micron Hydroponic Growing Plastic Film Greenhouse for Micro Green and Flowers
Greenhouse Features:
1. High adaptation can be used in many sence and more efficient than traditional greenhouse.
2. Anti-UV, anti-drip, anti-dust, anti-insect.
3.The cover can reduce the evaporation of soil water.
4.The temperature and light intensity can be adjusted according to the weather and needs.
5.The roof is usually arc-shaped, elegant and fluent visual sense.
Brand | Honyu | Product Name | Single Tunnel Film Greenhouse |
Cover Material | Different Thickness PE Film | Main Frame | Hot Dip Galvanized Steel |
Span Width | standard 8m span width | Length | At Least 30m |
Gutter Height | 3 m or 4 m are normal | Roof Height | 4.8 m or 5.8 m are normal size |
Normal Size | 16m * 32m | MOQ | 512 Square meter |
Snow Load | 0.3KN / ㎡ | Wind Load | 80-100km/h |
Hanging Load | 0.15 KN/ ㎡ | Rain Drainage | 140 mm/h |
Ventilation | Manual or Electric Roll UP | Customized | The Size Can Be Customized |
Detailed Images
Structure Of Single Tunnel Film Greenhouse (Above Picture Just For Reference)
Greenhouse Type | Arch Roof Type, Two Doors, Double Side Ventilation System |
Arch Pipe | φ32, φ42 ....Different size of hot dip glavanized steel pipe |
Longitudinal Pull rod | φ32, φ42 ....Different size of hot dip glavanized steel pipe |
Bracing | φ25, φ32, φ42 ....Different size of hot dip glavanized steel pipe |
Card Slot and Zigzag wire | Fixed Film, improve greenhouse struture tensity |
Other related accessories | Galvanized connectors, bolts and nuts etc. |
Customized Service | Greenhouse span width, legth, gutter height, roof height can be customized |
Framework:
1). Hot dip galvanized steel structure;
2). Stable structure, high intensity;
3). Assembly style without welding points;
4). Excellent anti-corrosion effectiveness;
5). Customized design and high quality material;
6). Long life time, assemble easily.
Roof Cover:
1) Film: PE. PVC.PO
2) Thickness: 80 micron, 100micron, 120 micron, 150 micron, 200 micron.
3) High light tranmission
4) life span time: 5-8 years
External Shading System: High quality shading net
Shading Rate: more than 80.7%
Internal Insulation System: Aluminum foil curtain
Shading Rate: 55%
Side Window Ventilation system
Wet curtain open system
Suuporting system | Function |
Roof and side ventilation system | Providing good air flow for greenhouse |
External shading system | In summer, it can lower inner temperature |
Internal Insulation system | In winter, Keep warm and prevent heat losing |
Wet pad and fan cooling system | Bring down 4-12 degree temperature inside of the greenhouse |
Irrigation system | Micro jet irrigation sytem, drip line/arrow irrigation system, sprinkler irrigation |
Soil-less Cultivation | hydroponic growing system, coconut substrate cultivation system |
Heating system | Coal-fired hot air blower, electric heating fan, wire soil heating,Plumbing heating system. you could choose these system to heating. |
Intelligence Control System | Real-time remote access to air temperature, humidity, soil maisture, carbondioxide, and video images inside greenhouse. |
Other Related Suporting system | These system can be provided according to customer's requirement |
Packing & Delivery
Packing: Safety packing or packing as customer's requirement.
Delivery: by sea or land
Time: Accoding to the production line and the demand of greenhouse.
Business Scope
SIngle Tunnel Film Greenhouse
This is one of the most economical greenhouse, easy to construction and installtion, and it is suitable for many area.
Multi-span Film Greenhouse
Used for larger space than single tunnel film greenhouse, it can be equipped with more supporting systems, provide a more moderate and suitable environment to plants and vegetables.
Glass Greenhouse
Venlo type greenhouse with characters of high light transmittance, stable structure, venlo roof and gutter drainage, it's used a lot for tomato, cucumber, lettuce production with intelligent climate control, and for scientific research.
PC Sheet Greenhouse
It is similar with glass greenhouse, just the cover material is polycarbonate. And it also be usd for vegetalble and flower growing, economial greenhouse restaurant, science reasearch and Etc.
Irrigation System
1) Micro Drip Irrigation System
2) Sprinkler irrigation System
3) Drip arrow irrigation system
Different iirigation system for different plants and growing application.
Hydroponic Growing System
1) Suitable for vegetable, lettuce or flower, etc.
2) Save the land, no soil is needed for hydroponics.
3) All the growing conditions can be controlled with hydroponics system.
4) Stable and high productivity with NFT gutter.
5) Save the pesticide, environment friendly.
6) Plants grow healthier and easy to havest.
The Selling of Other Related Accessories
1) Gear motor: MOQ 50 pieces
2) Film roll up motor: MOQ 50 pieces
3) Zig zag wire and card slot: MOQ 100 pieces
4) kinds of film: MOQ 10000 sqm
5 ) Etc.
Our Company
Chongqing Honyu Global Agri-Tech Co., Ltd. is a professional manufacturer and exporter of modern agriculture greenhouse and equipment, mainly specializes in research and development, design, production, construction, installation and selling of all kinds of greenhouse, agricultural and forestry irrigation, water-saving Irrigation, hydroponics and substrate culture for hobby and commercial growers.
We have our own factory base for producing greenhouse including the greenhouse frame and various parts and accessories. Thanks to years of experience in this industry, our strong sourcing and integrating ability, we've already established long term cooperation with wide range of related factories. All the products we produced and sourced are all manufactured under strict quality control system, as quality is always focus of our business.
We are always committed to customers' profit and provide the high quality products at most competitive price. Till now, we've constructed a lot of greenhouse and irrigation projects in China, and also exported to America, Canada, South Africa, Qatar etc. where we enjoy really good reputation for good quality and service.
Our Service
1.Product Consulting: Welcome your inquiries.
2.Scientific Design: We can provide scientific design according to your specific requirement .
3.Reasonable Quotation: After proper communication and understanding of your needs, we will try our best to give you the best plan with reasonable price.
4.Samples Available: We are pleased to provide samples to you for quality check.
5. Installation and maintenance: We will provide technical guidance for customers.
6. Greenhouse parts and accessories supply
7. We look forward to long cooperation relationship sincerely, so we will do our most to provide the best service for our customers.
Please contact with us directly with your requirement, we'll check and provide you our best solution accordingly A.S.A.P.
