ASTM D1238 Melt Flow Test Machine /Melt Flow Index Tester For Polymer Plastic Price
- Category: >>>
- Supplier: Dongguan Lizjin Electronic Technology Co. Ltd.
Share on (62259609901):
Product Overview
Description
Product Description
Product Application
The machine is used to measure the melt flow rate (MFR) of thermoplastic resin in quality control and research applications. It is suitable for PE, nylon, fluoroplastics and other engineering plastics which of higher melt temperature, and also suitable for PE, PP, ABS resin and other plastics which of lower melt temperature.
Specification
Model | LZJ-RZ-23 |
Power | AC220V±10% 50/60HZ |
Barrel parameters | Inner hole 9.55±0.025mm |
Pistons parameters | Piston head: 9.475±0.015mm |
Piston length | H=6.35±0.1mm |
Paramters | Extrusion hole 1=2.095±0.005mm |
Temperature parameter | With intelligent temperature control instrument, with four pairs of significant temperature setting control, PID parameters can be automatically set, precision up to ± 0.1 degree centigrade |
Temperature rangeradius | 400℃ |
Temperature accuracyblade to jawand dust collector | ±0.2 ℃ |
Display resolution | 0.1℃ |
Maximum comsuption | < 600W |
Temperature recovery time | less than 4 min. |
Weight parameters | |
Weight accuracy | ±0.5% |
Basic configuration | 0.325kg, 1.kg, 2.1kg, 3.kg, 5.kg, 10.0kg, 12.kg, 21.6kg |
Position detection | |
Loop distance from up and down | 30mm |
Control precision | ± 0.1mm |
Test flow control | |
Times of cutting the material | 0~10 times |
Material cutting interval | 0~999s(set reference Table 2) |
Control flow reaches the set temperature without volatility | |
Barrel temperature time | 15 min. |
Material be installed | 1 min |
Material sample temperature recovery time | 4 min. |
When binder set | 1min |
Detailed Images
Packaging & Shipping
Company Information
Our products
Our Services
If you face any problems in future during testing process we promise we will give you a reply within 48 hours and solution provide within 3 working days. We can offer operation video and English operation muanual. We can provide video-con.
Pre-sales service
*24-hour Online contact
*Choose the right model of the equipment according to customer's request
Middle service
*Give the best offer
*Support customization
* Do customer's request
*Choose payment term you convenient.
*Promptly production and delivery inform you in time.
*Can provide invoice value as you like to decrease your tax
After sale service
*1 year warranty service and all life maintenance
*Provide Free information (1. Product Instruction 2. Product
operation instruction/video 3. Experiment Test)
*Remote control technical consult
*Free installation DVD
*Maintenance plan
Certifications
FAQ
Q:Are your company a trading one or a factory?
A:Factory + trade (integration),we have our own factory.
Q:Do you accept customization service?
A:Yes, we can not only offer standard machines, but also customized machines according to your request. We will design until you are satisfied.
Q:What is your product warranty ?
A:1Year warranty, but lifetime for services.
Q How about the products quality?
A: Our products apply to ISO, ASTM, GB, etc.
