Glorair Dust Collector Air Filter Cartridge Pulse Jet Dust Extractor Air Filter

Product Overview

Description

Glorair Dust Collector Air Filter Cartridge, Pulse Jet Dust Extractor Air Filter





Our cartridge filters can be used for most of the industrial dust collections. From large particles like wood and grain to micron dusts such as welding and cutting fume, they can be collected by our cartridge filters efficiently. Our filters can not only installed our own dust collectors, but also installed in other brand dust collectors. We can supply special filter cartridges on customers’ request.























Chemical Resistance for Cellulose Media:	Chemical Resistance for Polyester Media:
Hydrolysis resistance: Fair Acid resistance: Fair Alkaline Resistance: Fair Dust Release: Good	Hydrolysis resistance: Good Acid resistance: Good Alkaline Resistance: Good Dust Release: Excellent











Cylindrical Cartridge Specifications:

Model	O.D.	I.D.	Length	Filter Area	Filter Media Type
HS/C 3266	324 mm	213 mm	660 mm	21.00 m2	Cellulose
HS/C 3566	352 mm	241 mm	660 mm	23.00 m2	Cellulose
HS/C 3288	324 mm	213 mm	880 mm	27.00 m2	Cellulose
HS/C 3290	324 mm	213 mm	915 mm	28.00 m2	Cellulose
HS/P 3266	324 mm	213 mm	660 mm	9.40 m2	Polyester
HS/P 3566	352 mm	241 mm	660 mm	9.40 m2	Polyester
HS/P 3288	324 mm	213 mm	880 mm	12.50 m2	Polyester
HS/P 3290	324 mm	213 mm	915 mm	13.00 m2	Polyester



Flange Top Cartridge Specifications:

Model	O.D.	I.D.	Length	Filter Area 1*	Filter Area 2*
HS/F 3266	324 mm	213 mm	660 mm	21.00 m2	9.40 m2
HS/F 3290	324 mm	213 mm	915 mm	28.00 m2	13.00 m2

 *: Filter Area 1: Cellulose,  Filter Area 2: Polyester



Lug Top Cartridge Specifications:

Model	PSD	Bottom Cap	Length	Filter Area 1**	Filter Area 2**
HS/L 3266	390 mm	324 mm	660 mm	21.00 m2	9.40 m2
HS/L 3288	390 mm	324 mm	880 mm	27.00 m2	10.70 m2
HS/L 3290	390 mm	324 mm	915 mm	28.00 m2	12.50 m2
HS/L 32130	390 mm	324 mm	1300 mm	41.00 m2	18.50 m2

**: Filter Area 1: Cellulose,  Filter Area 2: Polyester
