Digital panel meters are used in many automation and process control applications for industrial monitoring and control, with the features of high precision, good stability, direct reading, strong anti-interference ability, nice appearance and easy to install. It is important to monitor and control variables such as current, voltage, power, frequency, ect. A digital panel meter can perform these functions and more. Dixsen offers a complete range of digital panel meter from very basic indicators with no output(DB Series) to more complex types with inputs and outputs or alarm function(DX Series). With its modular design, the DX series offers great flexibility by providing input or output combinations.
Model
Frame Size
(mm)
Mode
Dispaly range
Class Index
Case Qty.(Pcs)
Item Code
DX-V96
96x96
-
0~600V
0.5
36
5096000
Direct input AC Voltmeter
Frame Dimension(mm)
Case Dimension(mm)
Hole Cutout Dimension (mm)
Width
Height
Width
Height
Depth
Width
Height
96
96
91
91
80
92
92
Accessories
1. Two clamping kits for flush mounting, user can complete the installment easily without tool.
2. A complete operating instruction manual included with each meter.
