DC500KG 9Ah battery wifi solar electric automatic gate opener sliding gate motor sliding gate opener

Share on (62261174986):


Price:$174.00

Quantity:


Product Overview

Description


Sliding



Main Features





1, Ultra-low power consumption in standby mode. Average power consumption is less than 0.05W, longer service life of the battery.





2, Electronic limit switch, never miss the limit switch position. Power failure or manual release would not affect the OPEN/CLOSE position any more.





3, Remote control learning more intelligent. Remote controls can be learned without disassembling the motor, bring more convenience to users.





4, Built-in battery of 9Ah. Integrated structure of motor and battery makes installation more convenient. Built-in large capacity battery exempts your extra worries about power failure.





5, Intelligent Soft Start-Slow Stop function makes gate running more smoothly, extend its service life. Speed and distance are adjustable according to the installation.





6, Intelligent Human-Machine interaction, indicator light feeds back the error information timely makes installation and testing easier.





7, Obstruction protection, anti-clip function when hitting the obstacles protects life and property safety better.





8, Battery low power protection. Auto-stop when battery power is low to avoid damaging the battery due to excessive discharge.





9, Infrared protection, device can be optional connected to ensure the passing safety.





10, Auto-Close function can be set on demand.








Specifications


















































































Model



SL500DCL



Driven Mode



Chain



Power supply



220V/50Hz;110V/60Hz



Motor power



150W



Gate moving speed



16-18m/min



Maximum weight of gate



500Kg



Remote control distance



≥30m



Remote control mode



Single button mode /   Three button mode



Limit switch



Electronic limit switch



Noise



60dB



Working duty



S2, 20min



Recording of up remote controls



100



Frequency



433.92 MHz



Working temperature



-20°C ~ +70°C



Package weight



10Kg



Battery Specification



12V/9Ah



Standard Configuration



1 motor, 1 built-in control board, 2 remote controls, 2 keys, 1*9Ah backup battery, 1 user manual, fixing hardware.



Optional Accessories



Photocell, gear rack, alarm lamp, mounting plate, wireless keypad, wireless wall button, etc.
