Контактор В соответствии с стандартом weikesen KCT 63 VCT 63A однополюсный без 110V 230V din рейку переменного тока бытовой контактор
- Category: >>>
- Supplier: Zhejiang Weikesen Power Technology Co. Ltd.
Share on (62264573239):
Product Overview
Description
Product Description
| Type | Width in 9mm Modules | ||||
| 1P | Rating(In) AC-7a | AC-7b | Control Voltage (VAC) 50Hz | Contact | |
 | 16A | 6A | 12 | 1NO | 2 |
| 24 | 1NO | 2 | |||
| 48 | 1NO | 2 | |||
| 220 | 1NO | 2 | |||
| 230…240 | 1NO | 2 | |||
| 25A | 8.5A | 220 | 1NO | 2 | |
| 230…240 | 1NO | 2 | |||
| 2P | |||||
 | 16A | 6A | 12 | 2NO | 2 |
| 24 | 2NO | 2 | |||
| 48 | 2NO | 2 | |||
| 220 | 2NO | 2 | |||
| 230…240 | 2NO | 2 | |||
| 12 | 1NO+1NC | 2 | |||
| 24 | 1NO+1NC | 2 | |||
| 220 | 1NO+1NC | 2 | |||
| 230…240 | 1NO+1NC | 2 | |||
| 20A | 6A | 230…240 | 2NO | 2 | |
| 25A | 8.5A | 24 | 2NO | 2 | |
| 48 | 2NO | 2 | |||
| 220 | 2NO | 2 | |||
| 230…240 | 2NO | 2 | |||
| 220 | 2NC | 2 | |||
| 230…240 | 2NC | 2 | |||
| 40A | 15A | 220…240 | 2NO | 4 | |
| 63A | 20A | 24 | 2NO | 4 | |
| 220…240 | 2NO | 4 | |||
| 100A | — | 220…240 | 2NO | 6 | |
