Portable Gas Analyzer sf6 gas leak tester sf6 comprehensive tester
- Category: >>>
- Supplier: Baoding Zhiwei Electric Power Technology Co. Limited
Share on (62268864591):
Product Overview
Description
Product Description
Portable Gas Analyzer sf6 gas leak tester sf6 comprehensive tester
1.Product overview
This product is a mix of SF6 humidity and concentration test. Two tests can be completed in one on-spot test, therefore saving the gas and reducing workload.
Features:
* Long service time
* Multiple measuring methods to meet different requirements
* Built-in gas filter and pressure maintaining valve
* Large-size liquid crystal display, easy operation
* User can calibrate on site
* Easy operation with touch screen
* Simultaneous display of all data
* Large capacity of data storage
2.Principle of measurement
Thermal conductivity sensor is applied when measuring gas concentration, with high accuracy and long service time.
Resistance capacity method is applied when measuring humidity, using DRYCAP® sensor with this principle, which has been used for nearly 60 years, thus enabling he humidity measurement instru ment to work smoothly under all sorts of extreme environments.
DRYCAP® sensor is highly accurate and stable in the long run, free form the impact of dust particles and most chemical pollutions.
This product is a mix of SF6 humidity and concentration test. Two tests can be completed in one on-spot test, therefore saving the gas and reducing workload.
Features:
* Long service time
* Multiple measuring methods to meet different requirements
* Built-in gas filter and pressure maintaining valve
* Large-size liquid crystal display, easy operation
* User can calibrate on site
* Easy operation with touch screen
* Simultaneous display of all data
* Large capacity of data storage
2.Principle of measurement
Thermal conductivity sensor is applied when measuring gas concentration, with high accuracy and long service time.
Resistance capacity method is applied when measuring humidity, using DRYCAP® sensor with this principle, which has been used for nearly 60 years, thus enabling he humidity measurement instru ment to work smoothly under all sorts of extreme environments.
DRYCAP® sensor is highly accurate and stable in the long run, free form the impact of dust particles and most chemical pollutions.
Specification
item | value |
Warranty | 1 year |
Type | Measuring Dew Point and Moisture in SF6 Gas |
Certification | CE |
Customized support | OEM |
Place of Origin | China |
Hebei | |
Brand Name | zhiwei electric |
Model Number | ZWZH-IV |
Product name | sf6 comprehensive tester |
Humidity range | Polymer thin film, dew point -80℃~+20℃ or -60℃~+60℃ |
SF6 purity range | 0~100%SF6(weight ratio) |
dew point accuracy | ±0.5℃(If below 0℃,sensor displays frost point) |
SF6 purity accuracy | ±0.1%,irrelevant of flow |
Inlet pressure | ≤1.0Mpa |
Operation temperature | -30~+50℃ |
Environment temperature | ≤90%RH |
Charging voltage | 220VAC±10% 50Hz |
Using time length | no less than 8 hours of continuous work |
Storage capacity | 60 |
Size | 360×350×160 |
Weight | 4.8Kg |
Operation method | touch input |
Output interface | USB2.0 communication connector，direct connection with laptops Printing method: supporting AC printing |
Packing & Delivery
sf6 comprehensive tester
1. Wooden box with foam inside.
2. Customer OEM packing is also available.
1. Wooden box with foam inside.
2. Customer OEM packing is also available.
