Power adapter bare PCB circuit board 100V 240V input AC DC power adapter PCBA
- Category: >>>
- Supplier: Shenzhen Zhongyilong Electronic Technology Co. Ltd.
Share on (62276306584):
Product Overview
Description
Product Description
Power adapter bare PCB circuit board 100V-240V input AC-DC power adapter PCBA
Stencil Size | 736x736mm |
Minimum IC Pitch | 0.2mm |
Maximum PCB size | 1200x 500mm |
Minimum PCB thickness | 0.25mm |
Minimum chip size: | 0201 (0.2x0.1)/0603 (0.6 x 0.3mm) |
Maximum BGA size: | 74x74mm |
BGA ball pitch: | 1.00mm (minimum), 3.00mm (maximum) |
BGA ball diameter: | 0.40mm (minimum), 1.00mm (maximum) |
QFP lead pitch: | 0.38mm (minimum), 2.54mm (maximum) |
Volume: | One piece to low volume production quantities Low cost first article builds Schedule deliveries |
Assembly type: | Surface mount(SMT) assembly DIP assembly Mixed(surface mount and through hole) technology Single or double sided placement Cable assembly |
Components type: | Passive components: As small as 0402 package As small as 0201 with design review Ball Grid Arrays(BGA): As small as .5mm pitch |
Parts procurements: | Turnkey(we supply the parts) Consigned(you supply the parts) You supply some parts, we do the rest |
Solder type: | Leaded Lead-free/ROHS compliant |
Other capabilities: | Repair/rework services Mechanical assembly Box build Mold and plastic injection. |
| Sample Lead time | Mass production lead time |
Single sided PCB | 1~3 | 4~7 |
Double sided PCB | 2~5 | 7~10 |
Multilayer PCB | 7~8 | 10~15 |
PCB and Assembly | 8~15 | 15~20 |
OEM/ODM/EMS Services for PCBA:
· PCBA, PCB Board assembly: SMT & PTH & BGA
· PCBA and enclosure design
· Components sourcing and purchasing
· Quick prototyping
· Plastic injection molding
· Metal sheet stamping
· Final assembly
· Test: AOI, In-Circuit Test (ICT), Functional Test (FCT)
· Custom clearance for material importing and product exporting
Capability - SMT
· Lines 9(5 Yamaha,4KME)
· Capacity 52 million placements per month
· Max Board Size 457*356mm.(18”X14”)
· Min Component size 0201-54 sq.mm.(0.084 sq.inch),long connector,CSP,BGA,QFP
· Speed 0.15 sec/chip,0.7 sec/QFP
Capability - PTH
· Lines 2
· Max board width 400 mm
· Type Dual wave
· Pbs status Lead-free line support
· Max temp 399 degree C
· Spray flux add-on
· Pre-heat 3
Related Products
Company Information
Certifications
FAQ
1. What professional service we offer ?
PCBA One-stop OEM service from PCB manufacture , Components sourcing , and then Assembly in house .
2. High quality control ability.
We provide 100% ICT Testing & 100% Function Testing for High quality control
3. MOQ.
No MOQ , and we provide samples testing before Mass production
4. Fast Delivery time.
PCB Samples or medium orders , 5-7 days, Mass production 2 weeks
PCBA samples or medium orders , 10-15days , Mass production 3 weeks.
