V350 гидравлический экскаватор, вибромолоток, приводы, лист, сваи
- Category: >>>
- Supplier: Shanghai Yongan Machinery Co. Ltd.
Share on (62278001007):
Product Overview
Description
Product Description
V-300 Excavator mounted vibratory hammer is used with excavator and installed on the first end of excavator. It's equipped with rotation gear box which can rotate 360 degree, with left and right rotating 180 degree each. And also Elastomer, which can reduce shock.
Data/Model | V-250 | V-300 | V-350 | V-400 | V-450 | V-500 | ||||
Eccentric Moment(kgm): | 4.8 | 5.3 | 5.8 | 6 | 6.5 | 7 | ||||
Frequency(HZ/rpm): | 43/2800 | 43/2800 | 43/2800 | 43/2800 | 43/2800 | 43/2800 | ||||
Centrifugal force(kN): | 413 | 457 | 500 | 517 | 560 | 603 | ||||
Hydraulic system operation pressure(bar) | 160 | 180 | 220 | 260 | 280 | 280 | ||||
Hydraulic system oil flow(lpm) | 165 | 210 | 235 | 280 | 280 | 280 | ||||
Weight (kg) (excluding clamp and vice arm) | 1700 | 1745 | 2010 | 2020 | 2050 | 2100 | ||||
Excavator Weight(kg) | 20-25 | 25-30 | 30-35 | 35-40 | 40-45 | 45-50 | ||||
Size(mm): (measure with C16 clamp) | 1530*1360*1540 | 1700*1600*1600 | ||||||||
Clamp model/weight(kg) | C15/588 | C15/588 | C16/680 | C16/680 | C16/680 | C16/680 | ||||
Vice arm model/weight(kg) | A200/2400*600*970/710KG | A250/2870*680*970/890KG | ||||||||
Features
1) 360 degrees rotation device of middle bracket
2) All kinds pile driving , sheet pile, tube pile, H beams, steel sheet.
3) Best mobility in narrow place compared with crane
4) High shear load of heavy duty elstomer cushion which prevent the transmission of vibration to excavator.
5) easy installation and control. Minimal noise which is appropriate various work sites, crowded area, under bridge, narrow road ways, urban renewal.
Projects
Certifications
Why Choose Us
1.Yongan machinery - piling equipment expert, over 30 years experience
Yongan Machinery Co., Ltd, one of the most professional vibratory hammer manufacturers in China, was established in 1985. After 30 years of development, our products take up 70% of the whole Chinese market. It becomes the leading company in vibratory hammers industry.
Yongan vibratory hammer series had been applied in more than 300 large projects (such as Hongkong-Zhuhai-Macao Bridge, Zhoudai Oversea Bridge, Shenzhen-Zhongshan Bridge, Russia Ketch Bridge, Nigeria Dangote Oil Refinery Project, Bangladesh Payra Bridge) .Our products are widely used not only in China but also in oversea market such as Japan, Korea, Taiwan, Indonesia, Malaysia, Ecuador, Russia, Libya, Vietnam Ghana and Philippines, etc.
2. powerful technical strength
Our technical won over 40 patents
John White - former founder of APE , father of vibro hammer join us ,works as engineer
3. Modern workshop + advanced production line ensure good quality
Our Service
Pre-Sales Service
* Inquiry and consulting support.
* View our Factory.
After-Sales Service
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
Packing & Delivery
Packaging | ||
Packaging Details | Hammer and vice arm are packed in shrink film, accessories in wooden box. | |
