3 year warranty meet room ip44 10w concealed led downlight
- Category: >>>
- Supplier: Zhongshan Guzhen Boyu Lighting Electronics Factory
Share on (62281920383):
Product Overview
Description
3 year warranty meet room ip44 10w concealed led downlight
Product Description
| DATASHEET | ||||
| Information | Model No. | BY-XTD-10W | BY-XTD-20W | BY-XTD-30W |
| Light source | SMD | |||
| Chip | 3030 2w | |||
| Electrical Information | Power(W) | 10/20/30W | ||
| Voltage | AC100-277V 50-60Hz | |||
| Driver efficiency | >90% | |||
| Power factor | 0.95 | |||
| Optical Information | Luminous flux(lm) | BY-XTD-10W | BY-XTD-20W | BY-XTD-30W |
| Luminous efficacy(lm/w) | 100LM/W | 100LM/W | 100LM/W | |
| CRI | >80 | |||
| Color temperature | 3000k/4000k/6500k | |||
| LED quantity(PCS) | 5 | 10 | 15 | |
| Beam angle | 65° | |||
| Mechanical Information | Housing material | Aluminum+Optical PC | ||
| Lens material | optical PC | |||
| Ambient temperature | -30℃~50℃ | |||
| IP Rating | IP44 | |||
| Packaging Information | Product size(MM) | 146*48*45 | 280*48*45 | 413*48*45 |
| cut out size(mm) | 140*35 | 270*35 | 405*35 | |
| Packaging size(CM) | 180*115*80 | 315*115*80 | 445*115*80 | |
| N.W. about(KG) | 0.216 | 0.384 | 0.55 | |
| G.W. about(KG) | 0.32 | 0.51 | 0.71 | |
