Features
Knob to adjust set temperature,gear indication/Temperature control/Heating control/Self testing
Specification
Range of measured temperature: -20~300℃
Range of set temperature: 0~200℃
Accuracy:±1℃ Heater:30A/250VAC
Dimension: 137mm×59mm×60mm
Mounting hole dimension: 112.5mm×39.5mm
| Code | Function | Set range | Default |
| E1 | Lower setpoint limit | -45℃~E2 | -35℃ |
| E2 | Higher setpoint limit | E2~120℃ | 120℃ |
| E3 | Temp.hysteresis | 1~50℃ | 4℃ |
| E4 | Comp.start delay time | 0~60Min | 2Min |
| E5 | Cold-room sensor correction | -30~30℃ | 0℃ |
