♦ Product name: AC series Air filter regualtor + Lubricator
♦ Ordering code:
AC 3000 - 03 - D
Model Valve body Port size D: With autodrain
♦ Characteristic:
1) This AC series is consisted of AF,AR and AL , each unit can be ordered separately. 2) The AF with water separate cleans the compressed air of fluid oil,condensation and dirt particles. For special application,the standard 40μm filter element may easily be replaced by a 25μm or 5μm filter element.
3) The AR maintain imputting constant operating pressure despite fluctuation in line pressure&the amount of air consumed. 4) The proportional lubricator adds a regulated quantity of oil to the filtered air. The oil-mist content proportional to the flow and oil can be added during operation. The oil drip rate is controlled by the adjustable bolt.Normally,1to 12 drops /1000L of the air is sufficient.
5) Different thread type can be offered according to customers' requirements, e.g.: PT, NPT etc.
♦ Specification:
Specification
Parameter
Applicable medium
Compressed Air
Pressure range
0.05~0.85 MPa
Proof pressure
1.5 MPa
Recommended oil use
ISO VG32 or the same grade oil
Temperature range
5°C~60°C
Advantages
Production Flow
company profile
Certifications
FAQ
1) Can you provide a sample before a big order?
Answer: Yes, we can provide a sample.
2) What 's the delivery date?
Answer: It depends on the quantity you order. Normally, it will take 10~15working days for our regular products.
3) Can you make NPT thread for the port size?
Answer: Yes, we can make NPT thread. But here is MOQ requirement for the quantity.
4) Are you able to make Non-standard or customized air cylinders?
Answer: One of our biggest advantage is for non-standard and customized products.
