4000L customized SS304 SS316 hot water storage tank

Product Overview

Description

professional design customized SS304 SS316 round square big small different shape mini water storage tank



solar power hot water professioal storage tank
Volume  (L)	In Dia  (mm)	Out Dia  (mm)	thickness of  I/O panel  (mm)	Tank  Height  (mm)	PU thickness  (mm)	Tank body  height  (mm)
1000	930	1030	0.6/0.5	1750	50	1500
1500	1180	1280	0.6/0.5	1700	50	1350
2000	1280	1380	0.6/0.5	1950	50	1600
2500	1300	1400	0.65/0.5	2250	50	1900
3000	1600	1720	0.65/0.5	2650	50	2260
4000	1710	1810	0.8/0.5	2350	50	2000
5000	1710	1930	0.8/0.5	2600	50	2250
6000	2130	2150	1.0/0.5	3000	50	2600
7000	2130	2350	1.2/0.8	2360	60	1970
8000	2130	2550	1.5/0.8	2600	60	2250
9000	2130	2750	1.5/1.0	2900	60	2520
10000	2130	2950	1.5/1.0	3150	60	2800



Volume: 3CBM (3000L).



Type: weld round type.



Inner layer: ss304,



Outer layer: SS201.



With PU insulation in the middle of two layer of panel.



Price: EXW: 5700RMB/set
