mini micro switch 15a 125 or 250vac
mini micro switch 15a 125 or 250vac

mini micro switch 15a 125 or 250vac

Share on (62287193449):


Price:$7.50 - $8.50

Quantity:


Product Overview

Description


Product Description
\t
Specifications
\t

Electrical
\t
Electrical Rating
\t
15A,125/250VAC;3/4HP,125VAC 1-1/2HP,250VAC
\t
Temperature Rating
\t
105℃ Std.(150℃ and 200℃ optional)
\t
Flammability Rating
\t
UL 94-V0
\t






Materials
\t
Case
\t
General Purpose PHenolic
\t
Actuating Button
\t
Themoplastic Nylon
\t
Common Terminals
\t
Brass
\t
No and NC Terminals
\t
Brass
\t
Moving Blade
\t
Brass
\t
Spring
\t
Stainless Steel (Nickel-Plated)
\t
Auxiliary Actuators
\t
Cold-Rolled Steel
\t
Roller
\t
Sintered Stainless Steel
\t
Contacts
\t
sliver-Cadmium Oxide
\t
Features
\t
5 current ratings
\t
Choice of actuator styles
\t
3 terminal types (optional screw terminals available--consult factory)
\t
3 contact arrangements
\t
Long-life coil spring mechanism
\t
High-temperature 150℃ and 200℃ available on select models(consult factoryy)
\t
Definitions of Operating Characteristic
\t
OF
\t
Operating Force
\t
PT
\t
Pretravel
\t
RF
\t
Releasing Force
\t
MD
\t
Movement Differential
\t
OT
\t
Overtravel
\t
OP
\t
OPerating Position
\t
TT
\t
Total Travel
\t
\t
\t
Operating characteristics
\t
OF(Max)
\t
850g
\t
OT(Min)
\t
2.03mm(0.080inch)
\t
PT(Max)
\t
1.27mm(0.050inch)
\t
MD(Max)
\t
0.38mm(0.15inch)
\t
PT(Max)
\t
1.27mm(0.050inch)
\t
OP
\t
17.2±0.76mm(0.670±0.30inch）
\t
Note#1:
\t
2NO OR2NC is available as request, please add '1' or '2' after the model.
\t
Example : S-19E1：2NO   S-19E2：2NC
\t
Note#2:
\t
Withh respect to operating sequence, pole 1 or 3 may operate first (virtually same time).
\t
If pole 1 or 2 must always operate in a particular sequence please contact us.
