FEIHU automatic high speed textile spinning drum winding machine wholesale

Product Overview

Description

FEIHU automatic high speed textile spinning  drum winding machine wholesale

It is a series of winder series produced by FEIHU textile machinery company. It is suitable for all kinds of raw materials such as silk, hemp, yarn, etc. cylinder. this machine has high characteristics productivity, low loss, low noise, long life, stable performance.



Using centralized control,individual management.

Using DC brushless motor,more power saving.

Using computer control,broken yarn stopped,metering count function.

Using soft start,less loss,easy to use

Using mechanical anti-stack,soft edge,make bobbin more uniform

Using lubricating oil,the noise is lower,accessories long service life

Adjustable forming length,shoulder angle and tension control.





Number	Winding machine
Model:	Single-sided single spindle, Centralized control
Spindle:	4 times the number of spindle, the standard 24 spindles / set
Spindle distance:	370mm
Oil way:	Automatic oiling, speed adjustable
Winding method:	Single spindle active precision winding
Winding shape:	Straight edge, bevel edge adjustable
Winding tube:	Parallel, pagoda tube
Winding travel:	120-230mm
Winding speed:	≤500 m/min
Winding diameter:	≤280mm
Skein diameter:	≤550mm
Cartridge diameter:	≤320mm
Actual power:	<120 W/spindle
Dimensions:	1620*710*1560 mm/group





FAQ

Q1: What's your payment term?

A. T/T  B. L/C



Q2: How long for the production?

A: Usually, it's around 15 to 25 days, which depends on the order quantity.



Q3: Packaging and shipping

A:.  Seaworthy export plywood cases packing or according to your request.
