Zigong Cemented Carbide Cutting Tools Type A Brazed Insert
1. 100% virgin raw materials.
2. Various kinds of grades are availalbe based on customer's application.
3. we have professional advanced production line and inspeciton equipments to ensure high quality products.
4. Precision Ground and high polishing process
5. High wear resistance,high hardness and impact toughness
6. Advanced technology , precise grinding.
Drawings
Type | Dimension(mm) | Approx unit weighting(g) | ||||||
| L | t | s | r | YG6 | YG8 | YT5 | YT14 |
B5 | 5.0 | 3.0 | 2.0 | 2.0 | 0.5 | 0.4 | 0.4 | 0.3 |
B6 | 6.0 | 4.0 | 2.5 | 2.5 | 0.8 | 0.8 | 0.6 | 0.6 |
B10 | 10.0 | 6.0 | 4.0 | 4.0 | 3.2 | 3.1 | 2.7 | 2.4 |
B12 | 12.0 | 8.0 | 5.0 | 5.0 | 6.1 | 6.1 | 5.5 | 4.8 |
B16 | 16.0 | 10.0 | 6.0 | 6.0 | 12.7 | 12.7 | 11.1 | 9.8 |
B20 | 20.0 | 12.0 | 7.0 | 7.0 | 22.4 | 22.4 | 19.6 | 17.2 |
B25 | 25.0 | 14.0 | 8.0 | 8.0 | 38.4 | 38.4 | 32.2 | 28.4 |
Product Display
Production Process-1
Company Information
Zigong Xingyu Cemented Carbide Dies&Tools Co.,Ltd is a professional supplier of tungsten carbide mould and customized tungsten carbide wear parts.Which integrates R&D, production, marketing and services.Established in 1999 and located in Zigong,Sichuan,China.We have 20 years experience in tungsten carbide products such as carbide molds & dies, bushings, valve seats, nozzles, inserts & cutting tools, carbide rods and bars, carbide plates & strips and other customized wear parts etc.
Our products have been exported to many countries.Being reliable and professional is our value of service. Providing customers with high satisfactory services and high quality products is always our mission.Sincerely welcome the friends all over the world to contact us for a WIN-WIN cooperation!
Worldwide Exhibitions and Customers
Packaging & Shipping
FAQ
Q1: Are you trading company or manufacturer ?
A1: We are a factory based in Zigong.
Q2: How long is your lead time?
A2: It depends on the quantity and customer’s design.Normally,about 15-20 days
Q3: Can you provide samples ? Is it free or extra ?
A3: Yes, we could offer the sample for free charge but buyer need to pay the cost of freight.
Q4: Can you support customized design?
A4: Yes,we accept OEM & ODM.
