Shape: | Round/Square/Rectangular/Oval |
Surface: | Polished,Pickled |
Heat treatment: | Solution, Annealed |
Melting point: | 1260-1340℃ |
Yield Strength(MPA): | ≥550 |
Elongation: | ≥30 |
Feature: | excellent corrosion resistan |
Width: | 600~1200mm |
Height: | 1000~2000mm |
Thickness: | 10~50mm |
Product Keywords | nickel plate 0.2mm,nickel inconel sheet,nickel alloy steel plate |
Product Introduce:
Nickel-chromium alloy INCONEL is an austenitic superheat-resistant alloy with nickel as its main component. Due to the strengthening effect of molybdenum and niobium solid solution contained in nickel-chromium alloy, it has super-high strength and excellent fatigue resistance in the range of low temperature to 1093 ℃. It is widely used in aviation industry and is suitable for making oxidation-resistant parts under 1100 ℃ under low load.
It has high tensile strength, fatigue strength, creep strength and fracture strength at 700 ℃, high oxidation resistance at 1000 ℃, stable chemical properties at low temperature, good weldability and workability.
Product Name Comparison:
Item | GB(China) | ASTM(Amecica) |
Inconel 600 | NS3102 | UNS N06600 |
Inconel 601 | NS3103 | UNS N06601 |
Inconel 625 | NS3306 | UNS N06625 |
Inconel 690 | NS3105 | UNS N06690 |
Inconel 718 | GH4169 | UNS N07718 |
Inconel X-750 | GH4145 | UNS N07750 |
Product Physical Constants:
Item | Tensile strength(Rm N/mm2) | Yield strength(RP0.2N/mm2) | Elongation(A5%) | HBS |
Inconel 600 | 500 | 180 | 35 | 185 |
Inconel 601 | 600 | 240 | 30 | 220 |
Inconel 625 | 830 | 414 | 30 | ≤290 |
Inconel 718 | 965 | 550 | 30 | ≤363 |
Inconel X-750 | 910 | 550 | 25 | ≤350 |
Product Chemical Components:
1,Inconel 600(UNS N06600)
% | Ni | Cr | Fe | C | Mn | Si | Cu | P | S |
Min | 72 | 14 | 6 | ||||||
Max | 17 | 10 | 0.15 | 1 | 0.5 | 0.5 | 0.015 | 0.015 |
2,Inconel 601(UNS N06601)
% | Ni | Cr | Fe | C | Mn | Si | Cu | Al | P | S |
Min | 58 | 21 | ||||||||
Max | 63 | 25 | Rest | 0.1 | 1.5 | 0.5 | 1 | 1.7 | 0.02 | 0.015 |
3,Inconel 625(UNS N06625)
% | Ni | Cr | Mo | Nb | Fe | Al | Ti | C | Mn | Si | Co | P | S |
Min | Rest | 20 | 8.0 | 3.15 | |||||||||
Max | Rest | 23 | 10 | 4.15 | 5 | 0.4 | 0.4 | 0.1 | 0.5 | 0.5 | 1 | 0.015 | 0.015 |
4,Inconel 718(UNS N07718)
% | Ni | Cr | Fe | Mo | Nb | C | Mn | Si | S | P | Cu | Al | Ti | B |
Min | 50 | 17 | Rest | 2.8 | 4.75 | 0.20 | 0.65 | |||||||
Max | 55 | 21 | Rest | 3.3 | 5.50 | 0.08 | 0.35 | 0.35 | 0.015 | 0.015 | 0.30 | 0.80 | 1.15 | 0.006 |
5,Inconel X-750(UNS N07750)
% | Ni | Cr | Fe | Nb+Ta | Co | C | Mn | Si | S | P | Cu | Al | Ti |
Min | 70 | 14 | 5.0 | 0.7 | 0.4 | 2.25 | |||||||
Max | 17 | 9.0 | 1.2 | 1.0 | 0.08 | 1.0 | 0.5 | 0.01 | 0.015 | 0.5 | 1.0 | 2.75 |
