Outdoor Station Polymer Post Insulator
- Category: >>>
- Supplier: RongZhao (Fuzhou) Imp & Exp Co. Ltd. [Fujian China]RongZhao
Share on (62300136431):
Product Overview
Description
Outdoor Station Polymer Post Insulator
|
Product Model |
Rated volt., kV |
Mechanical load,kN |
Height H,mm |
Insulation distance |
Creepage mm |
Lightning impulse mm |
Power Frequency withstand volt.kV |
| FZSW-10/4 | 10 | 4 | 215 | 125 | 290 | 75 | 42 |
| FZSW-24/8 | 24 | 8 | 300 | 220 | 750 | 150 | 65 |
| FZSW-36/9 | 36 | 9 | 450 | 360 | 946 | 185 | 95 |
| FZSW-66/10 | 66 | 10 | 760 | 630 | 2010 | 410 | 185 |
| FZSW-110/10 | 110 | 10 | 1220 | 1080 | 3530 | 500 | 230 |
| FZSW-220/8 | 220 | 8 | 2440 | 2200 | 7060 | 1000 | 395 |
