4K@60HZ Inserter & Extractor Support 2 DIP Switch To Extract The Digital HDMI Audio Signal And Embedding
- Category: Other Home Audio & Video Equipment >>>
- Supplier: Shenzhen Shunxun Electronics Co. Ltd.
Share on (62300234718):
Product Overview
Description
Product Description
4K@60HZ Inserter & Extractor Support 2 DIP Switch To Extract The Digital HDMI Audio Signal And Embedding
1). Support audio embedding, AUTO, SPDIF5.1, Analog Audio PCM2.0 output
2). Support 2 DIP switch to extract the digital HDMI audio signal from the HDMI input to 2 channel analog stereo output or 5.1 channel Audio output
3). Support audio uncompressed PCM, Dolby, DTS
4). Supports resolution up to 4K2K60HZ, bandwidth 18Gbps
5). HDCP2.2/1.4 Compliant
6). Support CEC
7). Support firmware updating through USB port
Detailed Images
Product Paramenters
Operating Temperature | 0 to +35°C (32 to +95°F) |
Operating Humidity Range | 5 to 90 % RH (no condensation) |
Input Video Signal | 0.5-1.0 volts p-p |
Input DDC Signal | 5 volts p-p (TTL) |
Video Format Supported | 4Kx2K/1080P/1080i/720P/576P/576i/480P/480i 3D video |
Audio Format Supported | PCM、DTS-HD Master Audio、Dolby true-HD etc. |
Support Video Color format | xv-YCC/deep color 36bit |
Data transfer speed rate | 18Gbps (Maximum) |
Power consumption | 1.5watts(Maximum) |
Net Weight | 155g |
Dimensions(WxHxD) | 104.4x89x28.3mm |
