tractor accessories dual control laser land leveling scraper grader

Product Overview

Description

  tractor accessories dual control laser land leveling scraper grader

Product Description

This 1JP series laser land leveler is used with 4-wheel farm tractor, can greatly hlep save water and make the land flatness tolerance below +/-2cm which is much better than ordinary irrigation method.

1. It can then save water by 20% or more.

2. By precision land levelling operation, can reduce the unnecessary ridge area by 3-5% to make good use of farm land.

3. With increased land flatness, it can help make fertilizer evenly distributed and increase the utilization rate by around 20%. It will then increase the crop yield by 20-30% with better water irrigation effect and the crop quality at the same time.

4. Better control of weed and pest damage.

5. Crop production cost saving by 5-15%



Specification:

Model	Unit	RTJP200	RTJP250	RTJP300	RTJP350
Working width	mm	2000	2500	3000	3500
Matched power	HP	60-70	75-95	100-150	More than 150
Efficiency	H m2/h	1.0-1.4	1.3-1.8	1.6-2.0	1.9-2.3
Working depth	mm	20-50
Ejector/acceptor		CP-210
Planeness	mm	±20-30
Signal reception angle	°	360 degree
Flatness		±15(Mm/100 square m)
Moldboard lift speed	mm/s	LIFT≥50, Down≥60
Cylinder settlement	mm/h	≤12
Working dip angle	°	10±2
Hydraulic oil pressure	Mpa	16±0.5
Wheel-base	mm	1600	1800	2000	2190
Pressure	kPa	200-250
Structural style		Traction
Applicable temperature	℃	-20℃+50℃
Size(L*W*H)	mm	3150	3150	3350	3350
	mm	2050	2650	3080	3550
	mm	3650	3650	3650	3650
Weight	kg	600	820	1140	1500



 Pictures:
