AUQ1 din rail mounting 6A Automatic power Changeover Switch

Product Overview

Description

Function and Feature:

Handle with 3 stage:I-O-II

Changeover switch with zero position in middle

Modularized and Din Rail mounting



Technical Data:

Rated Current(In): 6,10,16,20,25,32,40A

Rated Voltage(Un):230V/400V

Shell -grand Rated Current(In): 40A

Short-term Tolerance Rated Current:800A

Electrical endurance:10000 cycles

Mechanical endurance:20000 cycles

Numbers of Poles:1P,2P.3P.4P

Type of Terminal: Lug Type

Terminal Capacity: Cable up to  25mm²

Width: 17.6mm/module

Life: Operating cycle number 10000, which contained 1,500 (operating frequency

       for the 120 / h)

Use Category:AC-22

Protection Degree:IP20

Standards: IEC60947-3

Catalog No.                                                                                                               CTN Size:46.5x24x17.5cm

In(A)	Model No.	QTY/Box	QTY/CTN
6A	AUQ1 3P 6	4	40
10A	AUQ1 3P 10	4	40
16A	AUQ1 3P 16	4	40
20A	AUQ1 3P 20	4	40
25A	AUQ1 3P 25	4	40
32A	AUQ1 3P 32	4	40
40A	AUQ1 3P 40	4	40
