China QX inconel alloy 600 939 718 welding wire for sale
- Category: >>>
- Supplier: Shanghai Qiaoxin Industry Co. Ltd.
Share on (62308719059):
Product Overview
Description
Product Description
China QX inconel alloy 600 939 718 welding wire for sale
Product Detail
| Shape: | Wire |
| Surface: | Polished,Pickled |
| Outer Diameter: | 0.01-10mm |
| Material: | Nickle Material |
| Process method: | Cold rolled,hot forged |
| Melting point: | 1260-1340℃ |
| Yield Strength(MPA): | ≥550 |
| Elongation: | ≥30 |
| PRICE TERM: | CIF,CFR,FOB |
| Feature: | excellent corrosion resistan |
| Product Keywords | inconel alloy 600,inconel 939,inconel 718 welding wire |
Product Introduce:
Inconel is a Nickel-Chromium-Molybdenum alloy with low Carbon and Niobium addition, has superior resistance to high temperature effects such as oxidation and carburization as well as to a wide range of corrosive environments of unusual severity, especially resistance to pitting and crevice corrosion. Typical applications for inconel is seawater applications, aerospace components, chemical processing equipment, nuclear water reaction components.
Inconel series: 600,601,617,625,690,718,X750,825
Wire: 0.01-10mm
Ribbons: 0.05*0.2-2.0*6.0mm
Strip: 0.05*5.0-5.0*250mm
Bar:10-50mm
Product Physical Constants:
| Item | Tensile strength(Rm N/mm2) | Yield strength(RP0.2N/mm2) | Elongation(A5%) | HBS |
| Inconel 600 | 500 | 180 | 35 | 185 |
| Inconel 601 | 600 | 240 | 30 | 220 |
| Inconel 625 | 830 | 414 | 30 | ≤290 |
| Inconel 718 | 965 | 550 | 30 | ≤363 |
| Inconel X-750 | 910 | 550 | 25 | ≤350 |
Product Chemical Components:
1,Inconel 600(UNS N06600)
| % | Ni | Cr | Fe | C | Mn | Si | Cu | P | S |
| Min | 72 | 14 | 6 | - | - | - | - | - | - |
| Max | - | 17 | 10 | 0.15 | 1 | 0.5 | 0.5 | 0.015 | 0.015 |
2,Inconel 601(UNS N06601)
| % | Ni | Cr | Fe | C | Mn | Si | Cu | Al | P | S |
| Min | 58 | 21 | - | - | - | - | - | - | - | - |
| Max | 63 | 25 | Rest | 0.1 | 1.5 | 0.5 | 1 | 1.7 | 0.02 | 0.015 |
3,Inconel 625(UNS N06625)
| % | Ni | Cr | Mo | Nb | Fe | Al | Ti | C | Mn | Si | Co | P | S |
| Min | Rest | 20 | 8.0 | 3.15 | - | - | - | - | - | - | - | - | - |
| Max | Rest | 23 | 10 | 4.15 | 5 | 0.4 | 0.4 | 0.1 | 0.5 | 0.5 | 1 | 0.015 | 0.015 |
4,Inconel 718(UNS N07718)
| % | Ni | Cr | Fe | Mo | Nb | C | Mn | Si | S | P | Cu | Al | Ti | B |
| Min | 50 | 17 | Rest | 2.8 | 4.75 | - | - | - | - | - | 0.20 | 0.65 | - | - |
| Max | 55 | 21 | Rest | 3.3 | 5.50 | 0.08 | 0.35 | 0.35 | 0.015 | 0.015 | 0.30 | 0.80 | 1.15 | 0.006 |
5,Inconel X-750(UNS N07750)
| % | Ni | Cr | Fe | Nb+Ta | Co | C | Mn | Si | S | P | Cu | Al | Ti |
| Min | 70 | 14 | 5.0 | 0.7 | - | - | - | - | - | - | - | 0.4 | 2.25 |
| Max | - | 17 | 9.0 | 1.2 | 1.0 | 0.08 | 1.0 | 0.5 | 0.01 | 0.015 | 0.5 | 1.0 | 2.75 |
Company Information
About us
Shanghai Qiaoxin Industry Co.,Ltd.
is located in Shanghai, China.
Since its establishment, and more than 30 well-known domestic manufacturers cooperation, metal mainly.
We mainly operates metallic titanium and titanium alloy materials. We are a professional manufacturer for processing and producing metallic titanium, as well as titanium alloy materials. We are known for advanced processing technology, strong technical force, excellent quality, prompt delivery, and high credibility. We are able to achieve large-scale production of different thicknesses, different scales, different varieties and different specifications for different requirements of plates.We are able to use different classifications for production process.
Company Certificate:
Packaging & Shipping
PACKAGE:
Standard export carton packing or as according customer`s requirement.
DELIVERY TIME:
3-20 days after confirming order,detail delivery date should be decided according to
production season and order quantity.
