Aerogel insulation coating is a waterborne insulation coating taking aerogel micro-powder as skeleton,which solves the thermal insulation of industrial equipment and automobile parts,prevents hot scald of personnel, at the same time, green、energy saving and environmental protection can bring economic benefits to customers.
Thermal insulation
Unlimited by the base material、easy construction
Low density
Surface anti-scald
High solid content
Energy saving and environmental protection
Hydrophobic、anti-condensation
Product Data
Product Model
TEC - 001
TEC - 002
Thermal Conductivity
W/(m.K )
0.030- 0.035
0.035- 0.045
Density
(g/cm3 )
0.54±0.02
0.6±0.02
Volume Solids
（%）
70%- 73%
72%- 75%
Working Temperature
（℃）
- 45- 150
- 45- 240
Salt Spray Resistance
（h）
600
600
Ageing Resistance
（h）
600
600
Adhesion
（MPa）
≥1.5
≥1.5
Sunlight Than
0.88
0.88
Hemispherical Emissivity
0.81
0.81
Infrared Mirror Reflectance
0.9
0.9
Hydrophobic
Super-hydrophobic
/
Drying Time
（25℃）
Dry for 2h, can be heated quickly and dry, the whole drying time is more than 24h
Dry for 2h, can be heated quickly and dry, the whole drying time is more than 24h
