Metal Double Shafts Shredder Machine For Metal Recycling

Share on (62313876510):


Price:$9,000.00 - $10,000.00

Quantity:


Product Overview

Description


Metal Double Shafts Shredder Machine For Metal Recycling

Metal Double Shafts Shredder Machine For Metal Recycling
SCRAP METAL SHREDDER

This Metal Double Shafts Shredder Machine For Metal Recycling is widely used in various kinds of scrap metals, such as aluminum can bundle, steel drum, car shell, color steel tile, copper aluminum radiator, bicycle, etc.

Metal Double Shafts Shredder Machine For Metal Recycling
RAW MATERIAL

The raw materials of Metal Double Shafts Shredder Machine For Metal Recycling can be aluminum can bundle, steel drum, car shell, color steel tile, bicycle, copper aluminum radiator, oil filter, scrap wires, cables, aluminum composite plastic panel, steel wire rope, gas tank, iron scrap, zip-top can, engine case, paint bucket, etc.

Metal Double Shafts Shredder Machine For Metal Recycling
MACHINE FEATURES

Metal Double Shafts Shredder Machine For Metal Recycling is mainly composed of feed hopper, double shaft cutting system, PLC control system, discharging conveyor system and power system, etc;

Metal Double Shafts Shredder Machine For Metal Recycling

Blade materials include 9CrSi, Cr12MoV, SKD-II, D2, DC53, etc. It also can be customized.

Metal Double Shafts Shredder Machine For Metal Recycling

Steel plate of crushing chamber is very thick, so very strong and durable, long service life.

Metal Double Shafts Shredder Machine For Metal Recycling

We design shredder blades with different thickness for processing different raw materials.

Metal Double Shafts Shredder Machine For Metal Recycling

The bearing pedestal adopts the split type, easy to maintain and replace the blade.

Metal Double Shafts Shredder Machine For Metal Recycling

Button control, easy to operate, start, stop,forward, reverse, overload protection, etc.

Metal Double Shafts Shredder Machine For Metal Recycling

Feed hopper can be designed according to different raw materials.

WORKING PRINCIPLE

Metal Double Shafts Shredder Machine For Metal Recycling is the preprocessing equipment, the pre-sorted material to be chopped is fed into the two shafts whose rotors are moving slowly in opposite directions (therefore dust and noise free).

Metal Double Shafts Shredder Machine For Metal Recycling

The cutting discs are plugged on the shaft. This double shaft shredder is designed for longevity; The number of the knives or their width respectively determines the size of the output material.

Metal Double Shafts Shredder Machine For Metal Recycling
TECHNICAL PARAMETERS
ModelHNDM1000HNDM1200HNDM1500HNDM1900HNDM2600
Motor Power30*2 Kw45*2 Kw55*2 Kw90*2 Kw160*2 Kw
Capacity3-8 T/H5-10 T/H8-18 T/H10-25 T/H25-60 T/H
Blade Number34 Pieces30 Pieces38 Pieces34 Pieces25 Pieces
Input Opening Size1200*1000 mm1500*1200 mm2000*1500 mm2500*2000 mm3000*2500 mm
Dimension L/W/H3.6*1.5*2.2 m4.6*1.8*2.6 m5.2*2.0*2.6 m6.2*2.5*2.8 m8.2*4.0*4.3 m
Weight5 T8 T13 T18 T36 T
NOTE:

The Metal Double Shafts Shredder Machine For Metal Recycling is our standard configuration. For different raw materials to be shredded, the configuration might be different. Please feel free to contact us for detailed information or special request;

We design single or multi-hook blades with different thickness for different materials.

Metal Double Shafts Shredder Machine For Metal Recycling
FAQ
Q: When we establish one kind of shredder machine, can we use it to shred other materials?

A: Yes, you can. We will design the shredder machine for you as per your materials.

Q: How to choose a suitable shredder?

A: Please tell us your raw material and what capacity you need, we will recommend you the most suitable shredder.

Q: What About The Machine Installation?

A: For the Metal Double Shafts Shredder Machine For Metal Recycling installation, we will provide you the wire connection drawing and technical support, normally you can finish by yourself; but if you really need our technician, we will send technician to your working site as required.

Q: How About The Spare Parts?

A: We provide spare parts at cost price permanently and will give you the spare parts list when you purchase machine.

Q: Will you test the shredder machine before delivery?

A: Yes, we will test every machine and production line before delivery and send you the working video. You also can come to us for inspection before delivery.

WELCOME TO OUR FACTORY

Henan Honest Heavy Machinery Co.,Ltd is a professional company which is specialized in research and development, production and sales of renewable energy and organic solid waste environmental protection equipment.

Metal Double Shafts Shredder Machine For Metal RecyclingMetal Double Shafts Shredder Machine For Metal Recycling
OUR CUSTOMERS FROM OVER 30 COUNTRIES AND REGIONS
Metal Double Shafts Shredder Machine For Metal Recycling
