Intel I210 Based LRES2001PT POE PCIe x1 Gigabit Single Port Copper POE Ethernet Network Card Based On Intel I210 Chipset
- Category: Network Cards >>>
- Supplier: Shenzhen,Lianrui,Electronics,Co.,Ltd.
Share on:
Product Overview
Description
LRES2001PT-POE
Intel I210 Chipset Based PCIe x1 Gigabit Single Port Copper POE Ethernet Network Card
Product Description
LRES2001PT-POE is PCI Express x1 Single-port Copper Gigabit Ethernet PoE Industrial network card based on Intel I210 chip independently developed by Shenzhen Lianrui Electronics Co., Ltd. , compatible with PCIe x4, x8, and x16 channels. This POE Ethernet Network Card is mainly designed for industrial field visual inspection servers and devices, visual field clients, fast Ethernet data transmission equipment etc., as well as general servers.
The LRES2001PT-POE POE Ethernet Network Card compact design and does not reduce the performance of the NIC. It has extremely high network performance and reliability. Interruption adjustment improves performance while significantly reducing CPU usage. Compatible with the PCI-Express slot design for high-performance network transmission over the new PCI-Express desktop bus architecture while being compatible with Ethernet and Fast Ethernet to significantly reduce customer deployment and training costs. The POE Ethernet Network Card can be easily and quickly migrated to Gigabit Ethernet 10/100/1000Mbps auto-adapted to the stable, reliable operation of Ethernet, Fast Ethernet and Gigabit Ethernet compatible on the network, the Gigabit controller The related advanced configuration makes the power interface (ACPI) use less energy.
Features
LR-LINK unique design for POE Ethernet Network Card:
1, Single-port PoE output power consumption up to 30W;
2. Adaptive power output required for external devices: Class 0, Class 1, Class 2, Class 3;
3. The interface designed for industrial-grade cable accessm with LR-LINK customized industrial cable can more securely lock the cable and network port, effectively solve the problem of unstable network ports and cable connections in industrial sites. Also compatible with ordinary cable access;
4. Selected RJ45 connector with thickened gold to ensure more reliable connection;
Technology
POE Ethernet Network Card | |
Controller | Intel I210 |
Cable | Copper cable |
Cable Types | Cat 5E and Cat6:1000Base-T up to 100m (POE power supply Min requirement Cat5) |
Cat 5E and Cat6:100Base-T up to 100m (POEpower supply Min requirement Cat5) | |
Bracket | Low profile and Full-height Bracket |
Thermal design power consmption(max) | 1W |
PoE Output power consumption(max) | 30W |
Support OS | Windows 7 |
Windows 8/8.1 | |
Windows 10 | |
Windows Server 2003 /R2 | |
Windows Server 2008 /R2 | |
Windows Server 2012 /R2 | |
Windows Server 2016 /R2 | |
Linux Stable Kernel version 2.4.x / 2.6.x / 3.x /4.x or later | |
Red Hat Enterprise Linux 5 / 6 / 7 or later | |
SUSE Linux Enterprise Server 10/11 or later | |
VMware ESX/ESXi 4.x/5.x/6.x or later | |
FreeBSD 9 / 10 or later | |
Connector | 1*8-Pin RJ45 |
PCIe slot | PCI Express v2.1 (2.5GT/s) x1;compatible with x4, x8,x16 |
Connector Rate | 100Mbps/1000Mbps |
Power | Power by PCIe +12V±8% /+3.3V±9% |
Technical Features | |
Ethernet Power | Yes |
IEEE Standard | IEEE 802.3z IEEE 802.3 IEEE 802.1Q VLANs IEEE 1588 IEEE 802.3az - Energy Efficient Ethernet (EEE) IEEE802.3af IEEE802.3at |
PXE | Yes |
DPDK | Yes |
Jumbo frame packet | Yes |
ISCSI | Yes |
No | |
WOL | No |
Environment Features | |
Operating Temperature | 0 ℃ to 55 ℃(32 ℉ to 131 ℉) |
Storage Temperature | -40 ℃ to 70 ℃ (-40 ℉ to 158 ℉) |
Storage Humidity | 90% non condensing under 35℃ |
Certificates | FCC B, UL, CE, VCCI, BSMI, CTICK, MIC |
LED Indicators | |
LED Indicators | 1000Mbps:Yellow LINK LED,Green ATC LED blink |
100Mbps/10Mbps: Green ACT LED blink | |
Driver | |
Windows | |
Linux | Intel Corporation I210 Gigabit Network Connection (rev 03) |
Testing Report | |
Server/Client | CPU:Intel Xeon E3-1230 v5 @ 3.40GHz |
Motherboard:Intel S1200SPSR | |
RAM:8 GB ( Samsung DDR4 2133MHz ) | |
OS:Centos 7.0 | |
System Disk:eDlrre SSD ( 60 GB ) | |
TCP bandwidth/Throughput testing | Test the topology:S-C |
Server:iperf -s | |
Client:iperf -c 192.168.1.100 -P 6 -i 5 -w 512k -t 120 | |
942Mbits/sec | |
Typical test application platform | |
Server | DELL R710,DELL R720,DELL R730 |
Lenovo 8871 | |
HUAWEI H22M-03 | |
HP DL360P Gen8 (Blue screen) | |
Motherboard | Giada N50M-VU |
MSI B350M MORTAR | |
Supermicro Xl0SRL-F | |
Intel S1200SPS | |
Intel S1200BTL | |
Intel S1400PF | |
Intel S2600IP | |
ASUS X79Z | |
ASRock B250M-HDV | |
GIGABYTE B75-D3V | |
ASUS P8H77-V LE | |
Physical parameters | |
PCB size(mm) | 114*68.8*1.6 |
Weight(g) | 63 |
Ordering Information
Modle | Description | Notes | |
LRES2001PT- POE | PCIe x1 Gigabit Single-Port Copper POE Ethernet Network Card | Based on Intel(R) I210, 3U/2U bracket | |
