Lab Pouch Cell Hot Sealer Sealing Machine for Aluminum Laminated Film Battery Cup Top& Side edges sealing

Share on (62318306537):


Price:

Quantity:


Product Overview

Description




Pouch Cell Hot Sealer

STC-BRF200 pouch cell hot sealer is used for battery aluminum laminated film bag sealing before electrolyte injecting process. Copper sealing blade with good heating conduction. The temp of upper &lower sealing blade can be controlled separately and settable.


Technical Parameter


Model
STC-BRF200
Voltage
AC110V/ 220V optional
Power
1 kw
Sealing blade length
200mm, other size is available
Sealing blade width
5mm, other size is available
Upper sealing blade
RT~300℃, 200℃ is suggeted
Lower sealing blade
RT~300℃, 180℃ is suggested
Sealing time
2~3s, max 99s can be settable
Sealing pressure
0.5~00.7MPa
Dimension
L320 * W30 * H500mm
Weight
37 kg


Products Description



Pouch cell lab equipment:
STC-BRF200 pouch cell hot sealer is used for battery aluminum laminated film bag sealing before electrolyte injecting process. Copper sealing blade with good heating conduction. The temp of upper &lower sealing blade can be controlled separately and settable.

Features:
● The upper and lower sealing head temp can be controlled separately, digital display and adjustable for temp.
● Sealing head is made of copper with a good heating conduction.
● Embedded design for pressure guage, easy to observe the sealing pressure.
● Sealing time can be adjusted by timer.
● The sealing blade length is 200mm, other size can be customized.


Application:
● Battery lab
Battery research
Lithium ion battery lab
Material research
Trial-production


Recommend Products




Company Profile






Certifications




Exhibition




Contact Us




FAQ


1.Are you a manufacturer ?
A: Yes, our factory located in Shenzhen China,We have more than 9 years experience for producing battery equipment.We have our own designing and production department.

2.What certificate of your product have ?
A : Our products reaches CE certification.

3.Do you accept customized product ?
A : Yes.

4.Do you offer training service for users ?
A : Yes, we have video to show users how to use it.

5.Can you offer overseas installation service ?
A : Yes, we can.
