2KW Multi application Ultrasonic Metal Spot Welding Machine for Laboratory Lithium Battery Research
- Category: >>>
- Supplier: Shenzhen Tico Technology Co. Ltd.
Share on (62318359337):
Product Overview
Description
Technical Parameter
Model | STC-ECH2000 | ||||||
Voltage | AC110V/ 220V optional | ||||||
Output power | 2000w | ||||||
Generator frequency | 20KHz±100Hz | ||||||
Welding time | 0.1~2s | ||||||
Welding pressure | 0.5~0.7MPa | ||||||
Welding layers | 20 layers for reference, depending on different material | ||||||
Welding size | 4x4 mm, customized size is available | ||||||
Dimension | Controller: L600*W400*H350mm Welder: L800*W295*H495mm | ||||||
Weight | 80kg | ||||||
Products Description
STC-ECH2000 is an ultrasonic mental spot welding machine for Lithium-ion battery tab welding. This machine has the following advantages, firmly welding spot, low internal resistance of the welding spot, and neat appearance without oxidation traces. It can be applied in many effects by choosing relevant frequencies and powers according to different requirement.
Features:
● The conductibility after welding is good and the resistivity is very low.
● The welding can be perfectly conducted even if there are some contaminant or oxide exists on the metal surface. Ultrasonic have the function of cleaning.
● The workpiece don't need to pre-treatment. The fusion can be completed without solder and soldering paste, more economic, more convenient.
● The welding time is quite short, fusion can be completed within 0.1~2 seconds.
● The welding head is made of wear-resistant material and with great durability.
Application:
● Battery lab
● Battery research
● Lithium ion battery lab
● Material research
● Trial-production
● The welding can be perfectly conducted even if there are some contaminant or oxide exists on the metal surface. Ultrasonic have the function of cleaning.
● The workpiece don't need to pre-treatment. The fusion can be completed without solder and soldering paste, more economic, more convenient.
● The welding time is quite short, fusion can be completed within 0.1~2 seconds.
● The welding head is made of wear-resistant material and with great durability.
Application:
● Battery lab
● Battery research
● Lithium ion battery lab
● Material research
● Trial-production
Recommend Products
Company Profile
Certifications
Exhibition
Contact Us
FAQ
1. Are you a manufacturer ?
Tico: Yes, our factory located in Shenzhen China. We have more than 10 years experience for producing battery equipment. We have our own designing and production department.
2. What certificate of your product have ?
Tico: Our products reaches CE certification.
3. Do you accept customized product ?
Tico: Yes.
Tico: Yes, our factory located in Shenzhen China. We have more than 10 years experience for producing battery equipment. We have our own designing and production department.
2. What certificate of your product have ?
Tico: Our products reaches CE certification.
3. Do you accept customized product ?
Tico: Yes.
4. Do you offer training service for users ?
Tico: Yes, we have video to show users how to use it.
5. Can you offer overseas installation service ?
Tico: Yes, we can.
Tico: Yes, we have video to show users how to use it.
5. Can you offer overseas installation service ?
Tico: Yes, we can.
