VMC CNC фрезерный станок VMC650 Mitsubishi контроллер Vmc станок
- Category: >>>
- Supplier: Shandong Yangtuo CNC Machine Tool Co. Ltd.
Share on (62319240324):
Product Overview
Description
Product Description
VMC CNC milling machine VMC650 Mitsubishi Controller Vmc Machine
this VMC650 vertical machining center is suitable for producing metal product and parts in all shapes. It is widely used to
produce the auto spare parts, medical treatment instrument and any kind of injection mould, blowing mould, die-casting mould, car LED mould, toy mould and precise mould and so on. The size of the machine can be loaded into the container, easy to transport, and save freight.
produce the auto spare parts, medical treatment instrument and any kind of injection mould, blowing mould, die-casting mould, car LED mould, toy mould and precise mould and so on. The size of the machine can be loaded into the container, easy to transport, and save freight.
Table size | 1000x400 mm |
X axis travel | 600 mm |
Y axis travel | 400 mm |
Z axis travel | 500 mm |
Distance between spindle center and column | 446 mm |
Distance between spindle nose and table | 120-620 mm |
T-slot (No.* slot width *spacing) | 3-18*130 mm |
Spindle taper | BT40 |
ATC type | 16-tool arm/disc type or umbrella type |
Speed speed | 8000 rpm |
Spindle motor | 7.5/5.5 kw |
X.Y.Z axis servo motor | 1.0/1.0/1.5 kw |
Max.load capacity of work table | 500 kg |
X.Y.Z max. feed speed | 10/10/10 m/min |
X.Y.Z max. rapid traverse | 24/24/20 m/min |
X.Y.Z axis reposition accuracy | ±0.004 mm |
Dimension (L*W*H) | 2300×2200×2550 mm |
N.W. | 4500kg |
