Spring Stretch Compression Test Machine hz 3205

Product Overview

Description

Spring Stretch Compression Test Machine h2-3205



Product description

It is a special test equipment designed and manufactured according to the spring test specifications specified by national standards. It is suitable for the performance test of various springs such as tension spring, shock absorbing spring, gas spring and disc spring; it is the first testing equipment of spring manufacturer, spring unit and major testing institutions.

For many years, we have been working on spring testing equipment, and special equipment for various product development, widely used in shock absorbing springs, tension springs, scroll springs, wave springs, mold springs, pagoda springs, constant force springs, Drum spring, disc spring, torsion spring, leaf spring.



Main Specifications

Maximum test force	20KN
Test force bin	The whole process is divided into ×1, ×2, ×5, ×10
Range	0.5-100%
Test force accuracy	±1%
Displacement measurement accuracy	0.5%
Displacement resolution	0.01mm
Stretching space	600mm
Compressed space	600mm
test itinerary	600mm
Platen diameter	150mm
Displacement speed control range	0.01mm/min-300mm/min is adjustable
Deformation indication error	≤±(50+0.15L)
Test machine size	About 720×500×1780mm
Test machine weight	About 350kg
Test machine level	Level 1
Can be customized according to customer requirements
