China Brand RTK GPS Rtk GPS Chc X12 Rtk Gnss GPS



 X12 Inertial Navigation RTK is a revolutionary RTK. X12 inertial navigation RTK integrates the inertial navigation module on the basis of traditional RTK to realize the integrated solution of inertial navigation and satellite positioning and improve the user's operating efficiency by 20%. X12 inertial navigation RTK USES virtual eSIM to realize network operation without card. The application of these two technologies will lead the new trend of surveying and mapping equipment.



ItemContentsParametet Data
Satellites and precisionSatellite systemGPS+BDS+Glonass+Galileo, supporting beidou three generations
Wide area differentialSBAS + QZSS + IRNSS
L-band satellite station differenceOptional, convergence time 5 minutes
Resuming measurementoptional
The static accuracy

Plane accuracy :±2.5mm + 0.5× operating distance ×10-6 mm



Height accuracy :±5mm + 0.5× operating distance ×10-6 mm

Precision of RTK

Plane accuracy :±8mm + 1× operating distance ×10-6 mm



Height accuracy :±15mm + 1× operating distance ×10-6 mm

GNSS + inertial navigation (2)The output frequency200Hz
Tilt Angle0~60°
Tilt compensation accuracy10mm + 0.7mm /°tilt (30° internal accuracy <2.5cm)
The user interactionThe LCD panel1.46 inches, 128×128 resolution
Indicator light1 satellite light +1 differential data light
The keysFn function key + power/confirm key
voiceVoice support
The Web pageSupport PC/ mobile web pages
Physical propertiessizeφ190*98.5mm
The materialMagnesium alloy
The weight1.25kg
Working temperature-45℃~+75℃
Storage temperature-55℃~+85℃
Waterproof and dustproofIP68 (soak 1 meter under waterproofing)
The braceIK08 (mechanical impact force equal to that of 2.5kg steel hammer without damage and resistance to drop of 3m)
Waterproof and breathable filmPrevent water vapor from entering the equipment in harsh environment such as sun exposure and sudden heavy rain
Electronic bubbleSupport automatic measurement
Electrical propertiesThe batteryDual battery, 6800mAh, mobile station 10 hours of battery life
External power supply(9~28)V DC
storage32GB, 5 years typical data storage
Advanced featuresCloud service, base station mobile warning, base station power display, radio interference detection, data forwarding
Wireless communicationsNFCSupport wi-fi, bluetooth touch and flash receiver
eSIMYou can use CORS and network 1+N without card, and get 3 years' service fee free
network4 g netcom
radioSupport built-in/external radio
 Wi-fi data linksupport
Data outputThe differential dataRTCM2.X,RTCM3.X,CMR,CMR +,CMRx,RTCA
Location dataNMEA-0183,Trimble GSOF,NMEA2000
Static dataHCN,RINEX 2.11,RINEX 3.02
External data link radioThe user interactionLCD +4 direction keys +1 power/confirm key
Transmission power0 to 35 w is optional
Advanced featuresAutomatic matching baud rate, data forwarding and relay optional
Control the hand bookmodelHCE320
The operating systemAndroid 7.1
C P UEight-core 1.4ghz processor
network4G full network, dual Nano card +TF card switch
The LCD panel5.5 "AMOLED self-emitting capacitor screen
The battery8000mAh, fast charge support
Battery life20 hours
Waterproof and dustproofIP68
Tapping the pen
