ATEX UL844 IECEX Certed 40W Explosion Proof light Paint Spray Booth flood Lights
- Category: >>>
- Supplier: Hunan Kontak Technology Co. Ltd.
Share on (62325595765):
Product Overview
Description
SATEX UL844 IECEX Certed Explosion Proof Paint Spray Booth Lights 20W 30W 40W Class I Divison 2 IP68 IK09
Product Description
1.LED: LM80 certified, high efficacy, low decay, long lifespan.
Scientific optical reflector design, making the light more focus and distribute evenly.
2.Housing: Aluminum alloy ADC12, 1800ton high pressure die casting into lamp shape.
Patent designed to be Curved Fin Shape, maximize the best heat transmit
Surface treatment-Powder painted, salt&chemical resistant, also prevent dust and any
other particle to accumulate
3.Glass: Tempered glass, shock & vibration resistant, 4J direct impact. (IEC, ATEX, UL standards)
Super clear, >90% light transmit.
4.PCB: Aluminum thickness 2mm, Copper 2Oz.
Heat transmit 2.5, keep LED chip working under cool temperature.
5.Driver: Meanwell HLG series directly imported from Taiwan, >90% driver efficacy.
UL Certify, Excellent Design 2011 Award.
6.Circuit design: 5KV Surge Protection power supply.
Power factor≥0.95 and electrical efficiency between 87~92%.
7.Protection: IP68, high protection grade for waterproof and dust-proof
8.Working temperature: -40ºC to +55ºC
| Model | Led | Luminous | Reflector | Beam | CCT | CRI |
| No. | Quantity | Flux | Angle | (K) | ||
| (Pcs) | (lm) | (°) | ||||
| KTFL5209-200 | 156 | 21275 | Optional | 120*120 or RF60*30 | 2700~5700 | >75 |
| KTFL5209-150 | 156 | 17250 | Optional | 120*120 or RF60*30 | 2700~5700 | >75 |
| KTFL5209-120 | 156 | 13800 | Optional | 120*120 or RF60*30 | 2700~5700 | >75 |
| KTFL5209-100 | 84 | 11500 | Optional | 120*120 or RF60*30 | 2700~5700 | >75 |
| KTFL5209-80 | 84 | 9200 | Optional | 120*120 or RF60*30 | 2700~5700 | >75 |
| KTFL5209-40 | 24 | 4025 | Optional | 120*120 or RF60*30 | 2700~5700 | >75LT- |
PACKING INFORMATION
| Model | Light Size | Carton Size | QTY/CTN | Net Weight | Gross Weight |
| (mm) | (mm) | (pcs) | (kgs) | (kgs) | |
| KTFL5209-200 | 400*400*185 | 460*460*240 | 1 | 10.5 | 12 |
| KTFL5209-150 | 400*400*185 | 460*460*240 | 1 | 10.5 | 12 |
| KTFL5209-120 | 400*400*185 | 460*460*240 | 1 | 10.5 | 12 |
| KTFL5209-100 | 300*300*175 | 370*370*240 | 1 | 7.5 | 9 |
| KTFL5209-80 | 300*300*175 | 370*370*240 | 1 | 7.5 | 9 |
| KTFL5209-40 | 200*200*270 | 360*250*200 | 1 | 4 | 5 |
Installation Process
Company Information
Hunan Kontak Technology Co., Ltd.was founded in 2010, a professional import and export company. We specialize in producing and marketing LED lighting and solar products.
As time goes on, we have fostered good cooperative relationships with Chinese Electric Light Source Detection Institution and universities. We continue to evolve and devote ourselves to the development of the lighting industry and lighting related advanced technologies. In addition, Kontak invest heavily in R&D to build professional production team to get better service for customer.
We can fulfill any of your business needs and maximize your business profits compared with lots of other manufacturers. We are committed to providing quality products, competitive price, excellent services, quick response and prompt delivery.
"Client's need come first" is our principle. We sincerely welcome clients from all over the world to cooperate with us for mutual benefit in the near future.
Certificate
  |
|
Our Services
1. All inquiries will be replied with 24 hours.
2. Special discount is provided to each distributor, also customized order is available to every customer.
3. OEM&ODM, any your customized lightings we can help you to design and put into product range.
Quality Assurance: Product guarantee period is 3 years except for special indicated.
Attention: Protection of your sales area, ideas of design and all your private information.
Packaging & Shipping
We will use EMS, DHL, UPS, and China Post Air Mail to arrange the shipment. Parcels will be reached to your local place within 3~10 days after delivery
Packaging details | 1. The standard export packing and neutral packing. 2. Customized packing is available. |
Shipping details | 4 weeks or 15 working days after receipt of the payment |
